34
Parts List Models QS12 & QS24
DESCRIPTION PARTS
UPDATE
REMARKSW ARR.
CLASS
QS24
QTY.
QS12
QTY.
PART
NUMBER
GASKET --ACCESS COVER 074059 1 000 J9054573/UP 143
HARNESS--CONTROL TO REMOTE QS24 078618 1 2 103 CONTROL BOARD TO REMOTE KEY PAD
BOX
HARNESS--T/C LOWER *QS12* 079292 1 103 THERMOCOUPLES (6 L OWER COOKING
ZONES) REPLACE WITH 074178 -- T/C
LOWER FRONT QS, 074179 -- T/C LOWER
MIDDLE QS, 074180 -- T/C LOWER REAR QS
AS REQUIRED OR ALL 3 TO REPLACE
HARNESS.
HARNESS--T/C LOWER *QS24* 078643 1 103 THERMOCOUPLES (6 LOWER COOKING
ZONES) REPLACE WITH 074178 -- T/C
LOWER FRONT QS, 074179 -- T/C LOWER
MIDDLE QS, 074180 -- T/C LOWER REAR QS
AS REQUIRED OR ALL 3 TO REPLACE
HARNESS.
HARNESS--T/C UPPER #4 078622--4 1 1 103 THERMOCOUPLES (UPPER PLATEN ASSY.)
HARNESS--T/C UPPER #5 078622--5 1 1 103 THERMOCOUPLES (UPPER PLATEN ASSY.)
HARNESS--T/C UPPER #6 078622--6 1 1 103 THERMOCOUPLES (UPPER PLATEN ASSY.)
HARNESS--WIRE--LOWER POWER 074006 1 2 103 J9054573/UP 143
+CONNECTOR--HOUSING 3 PIN 078596 1 2 103
HARNESS--WIRE--LOWER POWER*QS24*
(OLD)
078620 1 2 103 POWER SWITCH TO INTERFACE BOARD
(PRIOR TO J9054573)
143
HARNESS--WIRE--UPPER POWER 074007 1 1 103 1 PER UPPER PLATEN
HEATER--CAST -- 1800 WATT 079639-- 3 6 103 J7100000/UP 122
HEATER--CAST -- 1400 WATT 078409-- 3 6 103 PRIOR TO J7100000 122
KIT A.--T-- HANDLE *QS12--QS24* X74326--KIT 1 1 103
+WASHER 078638 1 1 000
KIT A.--RELAY BOX A. (60HZ --OLD) X79897--SER 103 USE X74036--SER 135/143
LABEL --CAUTION--HOT SYMBOL 075717 --SYM 1 1 000 J9080000 TO K0100000
LABEL --PRODUCT 079714 1 1 000
LABEL --PRODUCT STOP BULLS EYE 079894 1 000 GROOVED PLATEN ONLY
LABEL --WARN--NO SPRAY SURFACE --SYM 074148--SYM 1 2 000 J9110000/UP
LEG--4”--3/8--16 STUD 036397 4 4 103
MAN--OPER QS24 050559--M 1 1 000
PANEL A.--CONTROL *QS12* X79265 1 103
PANEL A.--CONTROL *QS24* X78405 1 103
