PARTS LIST:
NOMENCLATURE DESCRIPTION PART # COMMENT
A1 Cooking Controller PP10940 Digital Control
A1 Cooking Controller PP11370 Single control computer, 12 Product
A1 Cooking Controller PP11371 Single control computer, 8 Product
A1 Cooking Controller PP11372 Dual control computer, 12 Product
F1 & F2 Fuse, 4 Amp Slow Blow P5045720
J1 15 position male connector PP10518
J2 & J15 12 position male connector PP10208
J3, J8 & J11 4 position male connector PP10203
J4, J5, J7 & J10 2 position male connector P5045839
J6 3 position male connector PP10089
J14 9 position male connection P5045838
K1, K2, K4 & K5 Relay, 24 vdc PP11124 Not used on Digital Control machines
K3 Relay, 24 vac P5046686 Used on Computer equipped machines only
M1 Right Basket Lift Motor PP10930
M2 Left Basket Lift Motor PP10931
P1 15 position female connector PP10519
P2 & P15 12 position female connector PP10209
P3, P8 & P11 4 position female connector PP10202
P4, P5, P7 & P10 2 position female connector P5045829
P6 3 position female connector PP10090
P14 9 position female connector P5045860
S1 & S3 Drain switch sensor PP10262
S1 & S3 Drain switch actuator PP10263
S1 & S4 Start switch PP10559 Computer equipped machines only
S2 & S3 Back Up Thermostat P5047587 Computer equipped machines only
S2, S4 & S7 Hi Limit Thermostat PP10304
S5 & S6 Basket Lift Micro Switch P5047169
T1 Transformer PP10439
