Top Panel Installation
Indoor walk-ins with dimensions of more than 15' 5" in both length and width (Figure #11) must have some type
support for ceiling panels. Exterior beams, interior beams or column supports can be used. In these cases, it is
imperative to properly install the rod assembly provided to properly support the ceiling panels and keep them from
sagging. Failure to do so may result in an unsatisfactory installation.
15' 5"
Not Applicable
When ceiling is not
supported on both sides
Figure #12
Warning! Top design is for zero load. Warranty may be void if top is
walked on, or other load is placed on top.
Figure #11
