27
LEVEL GAGE
0' - 5 1/2"
[140mm]
PRESSURE GAGE
3/8" MALE FLARE
RELIEF VALVE CONN.
1/2" DIA. K.O.
ELECTRICAL CONN.
(PUMPOUT POWER)
1' - 7 "
[483mm]
0' - 5 7/8 "
[149mm]
(2) 1" NPT RELIEF
VALVE OUTLET (SEE FIELD
INSTALLATION NOTES)
0' - 9 "
[229mm]
TYPICAL
B
T
R
E
D
W
0'- 9 7/8"
[249mm]
1" NPT
LIQUID CONN.
0'- 9"
[229mm]
TYPICAL
VAPOR
3/4" NPT
PUMPOUT CONDENSER
WATER INLET CONN.
1/2" MALE FLARE
VAPOR CONN.
3/4" NPT
PUMPOUT CONDENSER
WATER OUTLET CONN.
ELECTRICAL SERVICE
ACCESS SPAC E
20 3/4" X 8 3/4" X 4 1/2"
(BOTH SIDES)
V
U
N
A
G
M
J
K
L
F
1'-0 3/4"
[324mm]
3/8" MALE FLARE
RELIEF VALVE CONN.
1/2" DIA. K.O.
ELECTRICAL CONN.
(PUMPOUT POWER)
(FAR SIDE)
0'- 3 1/4"
[83mm]
0'- 10"
[254mm]
0'- 2 3/4"
[70mm]
0'- 7 15/16"
[202mm]
(FARSIDE)
C
P
S
H
DIMENSIONS
ENGLISH (ft-in.)
SI (mm)
TANK
SIZE
ABCDEFGHJK
0428 10- 5 9-10 4-4
1
/
4
2-4
3
/
4
1-2
3
/
8
3-1
1
/
4
6-4
3
/
16
3-11
3
/
8
3-4
7
/
8
2-9
9
/
16
0452 14-11
1
/
4
14- 4
1
/
2
4-8
1
/
4
2-8
1
/
2
1-4
1
/
4
3-4
1
/
2
7-2
1
/
4
4- 3
1
/
4
3-8
3
/
4
3-1
7
/
16
TANK
SIZE
L MNPRSTUVW
0428 3-4
5
/
8
0-3
1
/
2
4- 9
1
/
2
1-7
7
/
8
2-0
3
/
8
3-9 5-0
1
/
4
2-5 2-9
7
/
8
2-5
3
/
4
0452 3-8
1
/
2
0-3
3
/
8
6-11
5
/
8
1-8
3
/
4
2-0
5
/
8
4-1 5-0
1
/
2
2-5
1
/
4
2-10
1
/
8
2-6
TANK
SIZE
ABCDEFGHJK
0428 3175 2997 1327 730 365 946 1935 1203 1038852
0452 4553 4381 1429 826 413 1029 2191 1302 1137 951
TANK
SIZE
LMNPRSTUVW
0428 1032 89 1451 505 619 1143 1530 737 860 756
0452 1130 86 2124 527 625 1225 1537 742 867 762
NOTES:
1. Denotes center of gravity.
2. Dimensions in [ ] are in
millimeters.
3. The weights and center of
gravity values given are for an
empty storage tank.
4. For additional information on
the pumpout unit, see certified
drawings.
5. Conduit knockout is located
on the side of the control box.
6. 28 cubic ft storage tank
weight: 2334 lb (1059 kg).
7. 52 cu ft storage tank weight:
3414 lb (1549 kg).
Fig. 38 — Optional Pumpout Unit and Storage Tank
TOP VIEW
LEFT SIDE VIEW
FRONT VIEW
a23-1541
a23-1542
a23-1543
