Model EEG-141, 142, 143, 144
2-7. GAS LEAK TEST
2-8. GAS PRESSURE REGULATOR
SETTING
2-9. ELECTRICAL
REQUIREMENTS
Prior to turning the gas supply on, be sure the gas valve
knob on the gas control valve is in the off position.
Upon initial installation, and after moving the unit, the piping and
fittings should be checked for gas leaks. A simple checking method
is to turn on the gas and brush all connections with a soap solution.
If bubbles occur, it indicates escaping gas. In this event, the piping
connection must be redone.
To avoid fire or explosion, never use a lighted match
or open flame to test for gas leaks. Ignited gas could
result in severe personal injury and/or property dam-
age.
The gas pressure regulator on the gas control valve is factory set as
follows:
• Natural: 3.5 inches water column (0.87 kPa) (8.72 mbar).
• Propane 10.0 inches water column (2.49 kPa) (24.9 mbar).
The gas pressure regulator has been set by Henny Penny and is not
to be adjusted by the user.
• 120 V, 50/60 Hz, 1 PH, 12 A
• 230 V, 50 Hz, 1 PH, 7 A
The 120 volt gas fryer is factory equipped with a grounded
(earthed) cord and plug for your protection against shock, and
should be plugged into a three-prong grounded (earthed) recep-
tacle. Do not cut or remove grounding (earthing) prong. Any 230
volt plug used on the 230 volt unit must conform to all local, state,
and national codes.
To avoid electrical shock, this appliance must be
equipped with an external circuit breaker which will
disconnect all ungrounded (unearthed) conductors.
The main power switch on this appliance does not
disconnect all line conductors.
2-6 609
