Model EEG-141, 142, 143, 144
3-3 1009
3-1. OPERATING COMPONENTS
(Continued)
Fig. Item Description Function
No. No.
3-1 9 Press to turn on and off the heat system for the left vat(s); on full
vats either button can be used
3-1 10 & 11 Each product button LED lights when that particular product has
been selected, or when it is compatible with cook temperature
Press to select the desired product; press to place the letters
under the button, during naming a product in Program Mode
The can be used to start an Idle Mode if enabled in Special
Program Mode
3-1 12 During normal operation, press this button to start and stop
cook cycles for the right basket; press to change displayed
product; press to confirm prompts in the filter modes; also
used for
√ √
√ √
√ to indicate YES or confirmation
3-1 13 During normal operation, press this button to start and stop
cook cycles for the right basket; press to change displayed
product; press to deny prompts in the filter modes; also
used for X to indicate NO or cancel
3-1 14 Press to turn on and off the heat system for the right vat(s)
3-2 15 A Filter Beacon
®
is found beside each black drain knob; when
lit blue , indicates the oil should be filtered at this time;
beacon flashes when the drain needs opened or closed
3-3 16 When the power switch is turned to the ON position, power is
supplied to the controls and pumps
3-4 17 For fryers with a bulk oil supply, press this button to fill the JIB
