General Data
UNT-PRC001-EN
66
Basic Series
Table B-GD-1. Coil Data
Unit Size 04 06 08
Face Area Ft. 1.1 1.6 2.1
(cm) (1020) (1490) (1950)
LxDxHIn. (cm)
3-Row 20x2.6x8 29.5x2.6x8 38x2.6x8
(51x7x20) (75x7x20) (97x7x20)
4-Row 20x3.5x8 29.5x3.5x8 38x3.5x8
(51x9x20) (75x9x20) (97x9x20)
Volume Gal. (Liters)
1-Row (4-pipe only) .08 .11 .14
(.30) (.42) (.53)
2-Row (4-pipe only) .15 .22 .28
(.57) (.83) (1.06)
3-Row .23 .33 .42
(.87) (1.25) (1.59)
4-Row .30 .44 .56
(1.14) (1.67) (2.12)
Fins per Ft. (cm)
All coils 144 144 144
(4.7) (4.7) (4.7)
Table B-GD-2. Fan/Motor Data
Fan Quantity 1 2 2
Size Dia’’ x Width’’ (cm) 6.31x7.5 6.31x6.5 6.31x7.5
(16x19) (16x17) (16x19)
Motor Quantity 1 1 1
Table B-GD-3. Air Flow
ESP
Motor FD High Static
Unit Size Coil 0.05 0.1 0.2 0.3 0.4
04 3R144 370 550 510 470 430
4R144 340 510 480 440 400
06 3R144 610 890 830 770 710
4R144 560 820 760 710 660
08 3R144 730 1000 930 870 800
4R144 680 940 870 810 750
