4-8
REMOVING AN OVEN HALOGEN LIGHT &
THE OVEN TEMPERATURE SENSOR
CAUTION: When you work on the built-in
oven, be careful when handling the sheet metal
parts. Sharp edges may be present, and you
can cut yourself if you are not careful.
ELECTRICAL SHOCK HAZARD
Disconnect power before servicing.
Replace all panels before operating.
Failure to do so could result in death or
electrical shock.
WARNING
1. Disconnect the electrical power to the
oven.
2. Open the oven door and remove the racks
from inside the oven.
Oven Temperature
Sensor & Halogen
Lights
c) Pull the halogen bulb out of the socket.
Mounting Screw
Halogen Light
Assembly
Socket Assembly
3. To remove an oven halogen light:
a) Remove the lens from the halogen light
socket by lifting the end near the mount-
ing screw and unsnapping it.
b) Remove the screw from the halogen
light assembly.
Lift Lens Here
Halogen Bulb
