5-3
Refer to page 4-10 for the procedure for servic-
ing the broil element.
1. Disconnect the electrical power to the
oven.
2. Disconnect the wires from the broil ele-
ment terminals.
3. Set the ohmmeter to the R x 1 scale.
4. Touch the ohmmeter leads to the inner
broil element terminals. The meter should
indicate between 45 and 55 Ω.
5. Touch the ohmmeter leads to the outer
broil element terminals. The meter should
indicate between 45 and 55 Ω.
Outer
Element
Inner
Element
Outer
Element
ELECTRICAL SHOCK HAZARD
Disconnect power before servicing.
Replace all panels before operating.
Failure to do so could result in death or
electrical shock.
WARNING
BROIL ELEMENT
BAKE ELEMENT
ELECTRICAL SHOCK HAZARD
Disconnect power before servicing.
Replace all panels before operating.
Failure to do so could result in death or
electrical shock.
WARNING
Refer to page 4-12 for the procedure for servic-
ing the hidden bake element.
1. Disconnect the electrical power to the
oven.
2. Disconnect the wires from the bake ele-
ment terminals.
3. Set the ohmmeter to the R x 1 scale.
4. Touch the ohmmeter leads to the element
terminals. The meter should indicate be-
tween 25 and 30 Ω.
