4-12
REMOVING THE HIDDEN BAKE ELEMENT
1. Disconnect the electrical power to the
oven.
2. Pull the oven out of its mounting location
so that you can access the rear cover (see
page 4-4, steps 1 through 3 for the proce-
dure).
3. Remove the rear cover from the oven (see
page 4-5 for the procedure).
CAUTION: When you work on the built-in
oven, be careful when handling the sheet metal
parts. Sharp edges may be present, and you
can cut yourself if you are not careful.
ELECTRICAL SHOCK HAZARD
Disconnect power before servicing.
Replace all panels before operating.
Failure to do so could result in death or
electrical shock.
WARNING
5. Bend the cover flanges down as far as
they will go.
Bend Cover
Flange Down
Bend Cover
Flange Down
Cover Flange
& 2 Screws
Cover Flange
& 2 Screws
6. Use a pen knife or a single-edged razor
blade and cut the insulation blanket, as
shown. Be sure to separate the insulation
blanket as cleanly as possible.
Cut Insulation Blanket
7. Carefully move the insulation blanket out
of the way so that you can access the
hidden bake element mounting bracket.
4. Remove the four screws from the hidden
bake element cover flange.
Hidden Bake Element
