Filter
Top Products
1-5
Model Number
KEBS107D KEBC177H
Colors Available
SS BT, BL, WH
Model Description
Single Built-In Oven Single Built-In Oven
Size-Configuration
30" 27"
Dimensions/Specifications
Overall Height (in)
28 7/8" 28 7/8"
Overall Width (in)
29 3/4" 26 3/4"
Overall Depth Inc Hrdwr/Hndl (in)
25 1/8" 25 1/8"
Depth W/O Handle (in)
23 7/8" 23 7/8"
Cutout Dimensions
Cutout Height (in) (Measure Or Min/Max)
27 3/4" 27 3/4"
Cutout Width (in) (Measure Or Min/Max)
28 1/2" 25 1/2"
Cutout Depth (in) (Measure Or Min/Max)
23 1/4" 23 1/4"
Other Dimensions
Conduit Size (in) (Length/Diameter)
48"; 1/2" 48"; 1/2"
Net Weight (lbs)
126 126
Shipping Weight (lbs)
139 134
Total Connected Load in kW
240 Volts
4.9 kw 4.9 kw
208 Volts
3.7 kw 3.7 kw
240/120V AC
Circuit Amps
30 AMP 30 AMP
Exterior
Oven Front Frame
Porcelain Porcelain
Oven Control Type
Electronic Electronic
Bake
Standard Standard
Maxi Broil
Yes Yes
Econo Broil
Yes Yes
Convection
3rd Element 3rd Element
Child Lock Out
Yes Yes
Interior
Main Oven
Cooking System
True Convection True Convection
Cleaning System
Self Cleaning Self Cleaning
Auto Self Clean Latch
Yes Yes
Main Oven Liner Finish
Porcelain Porcelain
Main Oven Volume (cu ft)
4.24 3.58
Main Oven Height (in)
16" 16"
Main Oven Width (in)
25" 22"
Main Oven Depth (in)
18 1/2" 18 1/2"
Main Electric Oven
Main Hidden Bake Element
Yes Yes
Main Electric Element Output
Main Oven Bake (w@240/208v)
2000W/1500W 2000W/1500W
Main Oven Broil Inner Element (w@240/208v)
1667W/1250W 1667W/1250W
Main Oven Broil Outer Element (w@240/208)
1000W/750W 1000W/750W
Main Oven Convection )w@240/208v)
1600W/1200W 1600W/1200W
Miscellaneous
Cookbook Part/Comment
4449066 4449066
Installation Instructions Part/Comment
4450411 4448970
Service Manual Part/Comment
4317323 4317323
Tech Sheet Part/Comment
4451876 4451876
Use & Care Guide Oven Part/Comment
4450571 4449000
Other
Agency Approvals
UL, CSA UL, CSA
Installation Hardware
Yes Yes
Residential Use Only
Yes Yes
Under Counter Capability
Yes Yes
Warranty
Full (Months)
12 12
Extended
Electronic Controls (Months)
60 60
Electrical Elements (Months)
60 60
Porcelain Liner/Door (Months)
120 120
