7-2
SCHEMATIC DIAGRAM
M
~
M
~
L2N
L1
CONTROL POWER
TRANSFORMER
CONV. FAN
CONV.-1600W
BAKE-2000W
OUT BROIL-1000W
IN BROIL-1667W
HALOGEN
LATCH
SWITCH
DOOR ON LATCH ASSY
SWITCH
BR
BU
V
Y
GN
W
W
W
OR
Y
R
BU
OR
GY
BK
BK
GN
W
Y
R
BU
OR
5W/BULB
BK
W
LIGHT POWER SUPPLY
t°
t°
BK
(OPERATED BY
SOLENOID)
GND
BK
P4-1
P4-2
P1-1
P7-4
P7-8
P7-7
P7-2
P7-3
P7-6
P1-3
P6-2
P1-6
P5-3
P5-4
P5-1
P5-2
P1-5
P1-9
RETURN LINE MUST BE CONNECTED
P7-1
W
W
W
W
TA N
TA N
W
BK
W
R
W
DOOR LOCK
SOLENOID
BK
BLOWER
P3-5 P3-7 P3-2 P3-3
LATCH
DRIVE
CIRCUIT
+
–
P6-1
Y
+
–
18V DC
SOLENOID
GN
P3-1
THERMAL CONVECTION
MODELS ONLY
THERMAL CONVECTION
MODELS ONLY
BU
BU
R
R
NON-CONVECTION
MODELS ONLY
GN
ELECTRONIC
CONTROL
TEMPSENSOR
1080
AT 21 70°F)°C(
1654
AT 177 350°F)°C(
MEAT PROBE
78k
AT 15.6 0°F)°C(6
37k
AT 32.2 0°F)°C(9
THERMAL
FUSE/T.O.D.
GROUND (CHASSIS)
PLUG WITH FEMALE
CONNECTOR
RECEPTACLE WITH
MALE CONNECTOR
LIGHT
AC DRIVE
MOTOR
RELAY
CONTACTS
HEATING
ELEMENT
SOLENOID
ENCLOSED
THERMISTOR
OPERATED
BY DOOR
RELAY COIL
M
t
°
PIN FUNCTION COLOR
P6-1 LATCH SOLENOID (+ ) Y
P6-2 LATCH SOLENOID (
–
)W
P6-3 NOT CONNECTED
P6-4 NOT CONNECTED
P6-5 NOT CONNECTED
P6-6 NOT CONNECTED
PIN FUNCTION COLOR
P7-1 SWITCH COMMON (STROBE) TAN
P7-2 DOOR SWITCH BR
P7-3 LATCH SWITCH BU
P7-4 TEMP SENSOR V
P7-5 NOT CONNECTED
P7-6 GROUND GN
P7-7 MEAT PROBE SENSOR (GRND) GN
P7-8 MEAT PROBE SENSOR Y
ELECTRONIC CONTROL PINOUTS
PART NO. 4451876 REV. D
WIRE HARNESS SCHEMATIC
NOTES:
• When replacing the electronic control, be sure to
program the cavity size (see “Programming The
Cavity Size” on page 6-1).
• Dots indicate connections or splices.
• Circuit shown in STANDBY/OFF mode with
oven door closed.
