4-9
4. To remove the oven temperature sen-
sor:
a) Remove the two mounting screws from
the oven temperature sensor and pull
the connector out of the mounting hole
in the oven liner.
Oven
Temperature
Sensor
Sensor
Connector
d) Pull the halogen socket assembly out
of the oven liner and cut the wires near
the socket terminals.
e) Cut the new halogen light socket wires
to the proper length.
f) Remove 3/8˝ of insulation from the cut
wires on the wire harness and the halo-
gen light socket. Splice the halogen
light socket wires to the harness wires,
and twist two wire nuts over the bare
wire ends.
Cut Wires Here
Screws
b) Disconnect the sensor connector from
the main wire harness connector.
