5-2
Refer to page 4-14 for the procedure for servic-
ing the convection bake element.
1. Disconnect the electrical power to the
oven.
2. Disconnect the wires from the convection
bake element terminals.
3. Set the ohmmeter to the R x 1 scale.
4. Touch the ohmmeter leads to the element
terminals. The meter should indicate be-
tween 28 and 35 Ω.
Refer to page 4-14 for the procedure for servic-
ing the convection fan motor.
1. Disconnect the electrical power to the
oven.
2. Disconnect the wires from the convection
fan motor terminals.
3. Set the ohmmeter to the R x 1 scale.
4. Touch the ohmmeter leads to the motor
terminals. The meter should indicate be-
tween 8 and 12 Ω.
CONVECTION FAN MOTOR
ELECTRICAL SHOCK HAZARD
Disconnect power before servicing.
Replace all panels before operating.
Failure to do so could result in death or
electrical shock.
WARNING
ELECTRICAL SHOCK HAZARD
Disconnect power before servicing.
Replace all panels before operating.
Failure to do so could result in death or
electrical shock.
WARNING
CONVECTION BAKE ELEMENT
