4-17
REMOVING THE OVEN DOOR GLASS, HINGES, & HANDLE
1. Remove the oven door from the oven (see
page 2-3 for the procedure).
2. Place the oven door on a padded work
surface with the front decorative glass
facing down.
3. Remove the two top door liner screws and
the two door glass bracket screws, and lift
the liner assembly off the decorative door
glass and handle.
4. To remove the outer door glass:
a) Remove the three outer glass holder
screws and two outer glass bracket
screws from the door liner.
b) Lift the outer glass with the glass holder
off the door liner.
c) Remove the bracket.
5. To remove the center door glass, re-
move the bottom bracket, (it is loose), and
slide the two top corners of the glass out of
the door liner slots.
Top Liner Screws
Door Glass
Bracket Screws
Outer Glass Holder Screws
Outer Glass Bracket Screws
Outer Door Glass
Center Door Glass Corners
Remove Loose Bracket
Center Door Glass
Continued on the next page.
CAUTION: When you work on the built-in
oven, be careful when handling the sheet metal
parts. Sharp edges may be present, and you
can cut yourself if you are not careful.
