Model 8756Important: To the Operator
Symbol Definitions
To better communicate in the International arena,
the words on many of our operator switches and
buttons have symbols to indicate their functions.
Your Taylor equipment is designed with these
International symbols.
=AUTO
=ON
=OFF
=MIXREF
= WASH
=PUMP
= STANDBY
=MIXLOW
= MIX OUT
Power Switch
When placed in the ON position, the power switch
allows SOFTECH control panel operation.
Indicator Lights -
MIX LOW and MIX OUT
When the MIX LOW light begins to flash, the mix
tank has a low supply of mix and should be refilled
as soon as possible. When the MIX OUT light
begins to flash, it indicates the mix tank has been
almost completely exhausted and has an insufficient
supply of mix to operate the freezer. At this time, the
STANDBY and AUTO modes are l ocked out and the
freezer shuts down. To initiate the refrigeration
system, add mix to the tank and press the AUTO
key. The freezer will automatically begin operation.
Reset Button
The reset button is l ocated in the decorative plate
above the SOFTECH controls. The reset protects
the beater motor from an overload condition. Should
an overload occur, the reset mechanism will trip. To
properly reset the freezer, press the AUTO key to
cancel t he cycle. Turn the power switch to the OFF
position. Press the reset button firmly. Turn the
power switch to the ON position. Press the WASH
key and observe the freezer's performance. The
beater motor should be turning the drive shaft in a
clockwise (from operator end) direction without
binding.
If it is turning properly, press the WASH key to
cancel the cycle. Press the AUTO key on both sides
to resume normal operation. If the freezer shuts
down again, contact a service technician.
MIX REF
When the MIX REF key is pressed, the light comes
on, indicating the mix cabinet refrigeration system is
operating. There are two touch-tone panels, one for
each freezing cylinder. The mix refrigeration system
is controlled by the MIX REF key found on the left
panel. By pressing the AUTO key on either side of
the freezer, the MIX REF function is automatically
turned on. The MIX REF function cannot be
cancelled unless the AUTO or STANDBY mode is
cancelled first.
Standby
During long “No Sale” periods it becomes necessary
to warm the product in the freezing cylinder to
approximately 3 5_ to 40_F(1.7_to 4.4_C) to prevent
overbeating and product breakdown.
When the STANDBY key is pressed, the light comes
on, indicating the CTR (Cylinder Temperature
Retention System) has been activated. In the
STANDBY mode, the WASH, PUMP, and AUTO
functions are automatically cancelled. The MIX REF
function is automatically locked in to maintain the
mix in the cabinet.
To resume normal operation, press the AUTO key.
When the unit cycles off, the product in the freezing
cylinder will be at serving viscosity.
