Chapter 5 Replaceable Parts
Cabinet Parts and Hardware
Assembly-Level Service Guide 5-7
5
Table 5-3. HP 53131A/132A/181A Replaceable Parts
Reference
Designation
HP Part
Number
C
D
Qty Description
Mfr
Code
Mfr Part Number
EXCHANGE ELECTRONIC ASSEMBLIES
A1 (HP 53131A) 53131-60004 2 1 MOTHERBOARD 28480 53131-60004
53131-69004 0 1 MOTHERBOARD (EXCHANGE RESTORED) 28480 53131-69004
A1 (HP 53132A) 53132-60014 8 1 MOTHERBOARD 28480 53132-60014
53132-69014 6 1 MOTHERBOARD (EXCHANGE RESTORED) 28480 53132-69014
A1 (HP 53181A) 53181-60004 2 1 MOTHERBOARD 28480 53181-60004
53181-69004 0 1 MOTHERBOARD (EXCHANGE RESTORED) 28480 53181-69004
A3 (HP 53181) 53132-60003 5 1 OPTION 015, 1.5 GHz INPUT BOARD (RESTORED) 28480 53132-60003
A3 53132-60003 3 1 OPTION 030, 3 GHz INPUT BOARD (RESTORED) 28480 53132-60003
A3 53132-69211 1 OPTION 050, 5 GHz INPUT BOARD (RESTORED) 28480 53132-69211
A3 53132-69212 1 OPTION 124, 12.4 GHz INPUT BOARD (RESTORD) 28480 53132-69212
ELECTRONIC ASSEMBLIES
A2 53131-60002 3 1 DISPLAY BOARD 28480 53131-60002
A4 (Standard) 0950-2496 7 1 AC POWER SUPPLY (STANDARD) 28480 0950-2496
A4 (Option 002) 53132-60207 1 1 OPTIONAL AC POWER SUPPLY (002) 28480 53132-60207
A4 (Option 010/012) 53132-60208 2 1 OPTIONAL AC POWER SUPPLY (010 OR 012) 28480 53132-60208
A5 (Option 002) 53132-60206 0 1 OPTIONAL DC POWER SUPPLY (002) 28480 53132-60206
CHASSIS PARTS
H1 0515-0433 6 6 SCREW-MACH TORX 15 00000 ORDER BY DESCRIPTION
H2 0515-0430 3 3 SCREW-MACH TORX 10 00000 ORDER BY DESCRIPTION
H3 2940-0256 4 2 NUT-BNC 00000 ORDER BY DESCRIPTION
H4 0380-1332 7 2 SCREW-STDF, HP-IB CONN HEX 00000 ORDER BY DESCRIPTION
H5 2190-0577 1 2 WASKER-LOCK 00000 ORDER BY DESCRIPTION
H6 0590-0505 1 NUT-KNURLED 00000 ORDER BY DESCRIPTION
MP1 53131-00001 6 1 CHASSIS 28480 53131-00001
MP1 (Option 002) 53131-00010 6 1 CHASSIS, OPTION 002 28480 53131-00010
MP2 34401-86010 1 FRONT/REAR RUBBER BUMPER KIT 28480 34401-86010
p/o MP2 34401-86011 1 FRONT RUBBER BUMPER 28480 34401-86011
p/o MP2 34401-86012 1 REAR RUBBER BUMPER 28480 34401-86012
MP3 53131-00012 9 1 COVER 28480 53131-00012
MP4 53131-40009 8 1 FRONT BEZEL 28480 53131-40009
MP5 (HP 53131A) 53131-40015 6 1 WINDOW FOR HP 53131A 28480 53131-40015
MP5 (HP 53132A) 53132-40003 3 1 WINDOW FOR HP 53132A 28480 53132-40003
MP5 (HP 53181A) 53181-40013 4 1 WINDOW FOR HP 53181A 28480 53181-40013
MP6
(HP 53131A/132A)
53131-40010 1 KEYPADS FOR HP 53131/132A 28480 53131-40010
MP6 (HP 53181A) 53181-40012 3 KEYPADS FOR HP 53181A 28480 53181-40012
MP7 34401-45011 1 HANDLE 28480 34401-45011
MP8 53131-80038 7 1 REAR LABEL 28480 53131-80038
MP9 6960-0167 2 3 PLUG, HOLE 0.5-IN DIA 28480 6960-0167
0403-0424 8 1 RUBBER FOOT, BLACK 76381 SJ-5023
5041-0564 4 1 CAP 28480 5041-0564
