Chapter 6 Backdating
Backdating Hardware
6-6 Assembly-Level Service Guide
6
CHANGE 5 (Series 3705A to 3546A, 3548A)
Chassis color change only.
Page 5-7/Page 5-10, Table 5-3. HP 53131A/132A/181A Replaceable Parts:
Option 002
Option 015
Option 030
Option 050
CHANGE 6 (Below Series Prefix 3416A)
This change deleted three unnecessary connectors from the A1
(53131-60001) board.
Reference Designator/
Description Series 3705A
Series 3546A (53131A/132A)
Series 3548A (53181A)
MP2 Bumper/Cover Kit 34401-86010 34401-86000
MP3 Cover 53131-00012 53131-00002
MP4 Front Bezel (53131/132A)
MP4 Front Bezel (53181A)
53131-40009
53181-40011
53131-40001
53181-40001
MP5 Window (53131A)
MP5 Window (53132A)
MP5 Window (53181A)
53131-40015
53132-40003
53181-40013
53131-40002
53132-40001
53181-40003
MP6 Keypad 53131-40010 53131-40003
MP7 Handle 34401-45011 34401-45001
MP8 Rear Label 53131-80038 53131-80002
Kit-Rack Mount 5063-9240 5062-3972
MP10 Option 002 Rear Label 53131-80039 53131-80013
MP5 Window 1.5 GHz (53181A) 53181-40015 53181-40005
MP5 Window, 3.0 GHz (53181A) 53181-40014 53181-40004
Front Panel, 5 GHz (53131/132A) 53131-40012 53131-40006
Front Panel, 5 GHz (53181A) 53181-40016 53181-40006
MP5 Window, 5 GHz (53181A) 53181-40017 53181-40007
