FORM 160.55-O1 (604)
123
YORK INTERNATIONAL
3
FIG. 50 – SAMPLE PRINTOUT (TREND DATA NEW
OR EXISTING POINTS)
YORK TREND
CHILLER ID 163
© 1997 – 2000 YORK INTERNATIONAL COR PO RA TION
Mon 09 Oct 2000 3:33:47 PM
Data 1: Leaving Chilled Liquid Temperature
Data 2: Return Chilled Liquid Temperature
Data 3: Evaporator Pressure
Data 4: Leaving Condenser Liquid Temperature
Data 5: Return Condenser Liquid Temperature
Data 6: Condenser Pressure
Time Data 1 Data 2 Data 3 Data 4 Data 5 Data 6
3:33:47 PM45.5 °F55.0 °F 6.3 PSIA 95.0 °F 85.0 °F 1 8 . 7
PSIA
3:33:48 PM45.5 °F55.0 °F 6.3 PSIA 95.0 °F 85.0 °F 1 8 . 7
PSIA
3:33:49 PM45.5 °F55.0 °F 6.3 PSIA 95.0 °F 85.0 °F 1 8 . 7
PSIA
FIG. 51 – SAMPLE PRINTOUT
(CUSTOM SCREEN REPORT))
FIG. 52 – SAMPLE PRINTOUT
(ADAPTIVE CAPACITY CON TROL
NEW MAP POINT REPORT)
Log Time: Mon 12:45:39 PM 21 Jun 1999
D-P/P= 0.92; Prv Pos= 56; Freq= 39 Hz
Surge Type = Delta P/P Surge
Leaving Chilled Active Setpoint = 45.0 ~F
Leaving Chilled Liquid Temperature = 50.0 ~F
Return Chilled Liquid Temperature = 59.3 ~F
Leaving Condenser Liquid Temperature = 85.0 ~F
Return Condenser Liquid Temperature = 94.9 ~F
Evaporator Pressure = 7.2 Psia
Condenser Pressure = 13.8 Psia
% Full Load Amps = 94 %
D-P/P = 1.20; Prv Pos = 89; Freq = 58 Hz
D-P/P = 1.41; Prv Pos = 71; Freq = 46 Hz
D-P/P = 0.98; Prv Pos = 73; Freq = 52 Hz
D-P/P = 0.71; Prv Pos = 86; Freq = 39 Hz
D-P/P = 0.86; Prv Pos = 53; Freq = 48 Hz
D-P/P = 1.14; Prv Pos = 76; Freq = 51 Hz
D-P/P = 0.84; Prv Pos = 84; Freq = 37 Hz
D-P/P = 0.99; Prv Pos = 63; Freq = 46 Hz
FIG. 53 – SAMPLE PRINTOUT
(ADAPTIVE CAPACITY CONTROL EX IST ING
MAP POINTS REPORT)
YORK CUSTOM VIEW
CHILLER ID 0
(c) 1997 – 2001 YORK INTERNATIONAL CORPORATION
Mon 21 Jun 1999 1:28:25 PM
Leaving Chilled Liquid Temperature = 45.0 ~F
Return Chilled Liquid Temperature = 55.0 ~F
Leaving Condenser Liquid Temperature = 95.0 ~F
Return Condenser Liquid Temperature = 85.0 ~F
Evaporator Saturation Temperature = 41.0 ~F
Condenser Saturation Temperature = 78.5 ~F
Evaporator Pressure = 17.0 Psid
Condenser Pressure = 64.0 Psid
Oil Pressure = 45.0 Psid
% Full Load Amps = 50 %
