Operation, cont’d
SGS 408 Switcher • Operation3-12
Edit Prog
Exit Title Lock LCD Reset
Figure 3-23 — Performing a reset
2. From the reset submenu, select either preview reset (PRE), program reset
(PRG), both preview and program reset (Both), system reset (System), or
escape (ESC) to return to the previous submenu (figure 3-24).
Figure 3-24 — Selecting the reset type
3. If System is selected, the system reset submenu is displayed (figure 3-25).
Press the System button to reset the system, or press the ESC (escape) button
to cancel the system reset and return to the previous menu, or wait for the
16-second timeout to return to the default menu.
Figure 3-25 — Selecting the system reset
PRE PRG Both System ESC
!! CAUTION - RESETS ACTIVE !!
Select Which to Reset
System ESC
!! SYSTEM RESET CONFIRM !!
Press "System" to Confirm
