4-7SGS 408 Switcher • Serial Communication
Query Software Version
Q/q Ver x.xx
Example response: Ver 1.23
Request Part Number
N/n Nxx-xxx-xx
N60-341-01
Request Information
Program or preview
X2
I/
X2
iC
X1
•Frz
X15
•Mut
X15
•Hrt
X16
•Vrt
X16
General I/i Exe
X15
•Loc
X15
•Dvi
X15
Examples: 1I C2•Frz 0•Mut 0•Hrt 112.20•Vrt 75.02
Program information: Input channel 2, freeze mode is off, mute
mode is off, horizontal refresh rate is 112.20 kHz, vertical refresh
rate is 75.02 Hz
I Exe 0•Loc 1•Dvi 1
General information: Executive mode is off, program lockout is on,
DVI connector is installed
Advanced Instructions
The Advanced Instructions use hex commands that are more complex than the
Simple Instruction Set.
COMMAND HEX RESPONSE
Read/Write Entire Memory
Read (upload) 90 91 8 kbytes of data + 1 byte checksum
Write (download) 90 92 + 8 kbytes of data + 1 byte checksum Dnl
Read/Write Memory Block
Read to current memory block
X2
90 93 16 bytes of data + 1 byte checksum
Write to a user preset
X3
90 94 + 16 bytes of data + 1 byte checksum Dnl
Control Software for Windows
The SGS 408 Control Program, which is used by the SGS 408, is compatible with
Windows 95/98/2000, and NT. It provides remote control of various functions
including input selection, picture controls, effects, transitions, and output rates.
If an ECP 1000 event control panel is attached to the SGS 408, refer to the
ECP 1000 User’s Manual for information on running the SGS 408 Control
Program.
Installing the software
The program is contained on a set of 3.5-inch diskettes. To install the program
from the floppy disk to the hard drive, run SETUP.EXE from the floppy disk and
follow the instructions that appear on the screen. The program occupies
approximately 3 MB (megabytes) of hard-drive space.
By default, the Windows installation creates a C:\SGS408 directory, and it will
place two icons (SGS 408 Control Pgm and SGS 408 Help) into a group or folder
named “Extron Electronics”.
