Model EEE-141,142, 143, 144
Upon initial start-up, the controls will ask to confirm the settings for
the fryer.
When the main power switch is turned on, “OFF” shows in both
displays. Press on either side and *SETUP* *ENTER
CODE* shows in the displays. Press 1, 2, 3, and “LANGUAGE”
shows on the left display, “ENGLISH” on the right display.
Use or buttons to change the operation display to,
“FRANCAIS”, “ESPANOL”, “PORTUG”, “DEUTSCHE”,
“SVENSKI”, “RUSSIAN”.
Press to continue with the other set-up items which include:
• TEMP FORMAT -
o
F or
o
C
• TIME FORMAT - 12-HR OR 24-HR
• ENTER TIME - Time of day (use product buttons to change)
• ENTER TIME - AM OR PM
• DATE FORMAT - US (MM-DD-YY) or
INTERNATIONAL (DD-MM-YY)
• ENTER DATE - Today’s date (use product buttons to change)
• DAYLIGHT SAVING TIME - 1.OFF; 2.US (2007 & after);
3.EURO; 4.FSA (US before 2007)
• FRYER TYPE - ELEC or GAS
• VAT TYPE - FULL OR SPLIT
• AUTOLIFT ENABLED? - NO LIFT or YES LIFT
• BULK OIL SUPPLY - YES or NO
• BULK OIL DISPOSE? - YES or NO
• S/N - Shows serial number of the unit or can be recorded (THIS
SERIAL NUMBER SHOULD MATCH THE SERIAL
NUMBER ON THE DATA PLATE, ON THE DOORS.)
• 2nd LANGUAGE - By setting a second language in the controls,
2 languages can now be easily chosen by pressing during
normal operation.
One language shows in the left display and the second language
shows in the right display. Pressing the
√√
√√
√ button under the desired
language, selects that language seen in displays.
• 2nd VOLUME - By setting a second volume in the controls,
2 volumes can now be easily chosen by pressing twice
during normal operation.
One volume setting shows in the left display (NONE to 10; 10
being the loudest) and the second volume shows in the right
display. To select the volume, press the
√√
√√
√ button under the desired
volume .
• SETUP COMPLETE
Unless otherwise indicated, use or to change settings.
The Setup Mode can also be accessed by re-initializing the controls,
in Special Program Mode, in Level 2 programming (SP-3).
3-5 909
3-2. SET-UP MODE
