Models C709 & C717Operator Parts Identification
Model C709 Single Spout Door and Beater Assembly
Figure 2
ITEM DESCRIPTION PART NO.
1 HANDLE A.-DRAW-WELDED X56246
2 O-RING-1/4 OD X .070W 50 015872
3 SCREW-ADJUSTMT-5/16-24 056332
4 NUT-STUD BLACK 3.250” 058765
5 NUT-STUD BLACK 2.563“ 058764
6 DOOR A.-W/BAFFLE X57332-SER
7 VALVE A.-DRAW X55820
8 O-RING-DRAW VALVE-S.S. 014402
ITEM DESCRIPTION PART NO.
9 PIN-HANDLE-SS 055819
10 GASKET-DOOR HT 4”-DBL 048926
11 BEARING-FRONT 050216
12 BEATER A.-3.4 QT HELICORE X31761
13 BLADE-SCRAPER-PLASTIC 035174
14 SHAFT-BEATER 056078
15 SEAL-DRIVE SHAFT 032560
