Verification and Performance Tests 23
Table 2-7. Performance Test Record for Model Agilent 66106A (200V, 0.75A)
Pre Cal_____________Post Cal______________
Model Agilent 66106A Temperature___________________________Test Performed
By______________________
Serial Number_______________________Humidity________________________Date__________________________
Test Description Specification Measurement
Uncertainty
Actual
CV PROGRAMMING @ 0 volts
Output Accuracy (DVM Reading)
Display and Readback Accuracy
0
±
90mV
DVM
±
54mV
2.6
µ
V
2.6
µ
V
________
________
CV PROGRAMMING @ full-scale
Output Accuracy (DVM Reading)
Display and Readback Accuracy
200V
±
150mV
DVM
±
94mV
2.7mV
2.7mV
________
________
CV LOAD EFFECT 7mV
350
µ
V
________
CV SOURCE EFFECT 5mV
350
µ
V
________
CV NOISE (PARD)
Peak to Peak
Rms
50mV
30mV
1.5mV
5.0mV
________
________
TRANSIENT RECOVERY in 1 ms 100mV 15mV ________
CC PROGRAMMING @ 0 amps
Output Accuracy (Io)
Display and Readback Accuracy
0
±
0.4mA
Io
±
0.3mA
15
µ
A
15
µ
A
________
________
CC PROGRAMMING @ full-scale
Output Accuracy (Io)
Display and Readback Accuracy
0.75A
±
625
µ
A
Io
±
450
µ
A
100
µ
A
100
µ
A
________
________
CC LOAD EFFECT
10
µ
A1
µ
A
________
CC SOURCE EFFECT
30µA1µA
________
CC NOISE (RMS) 1mA 0.2mA ________
