Replacement Parts 71
Table 5-1. Agilent 6610xA Power Modules Parts List - Electrical (continued)
Reference
Designators
Model Part Number Description
C433 All Models 0160-4791 CAP l0pF 5% 100V
C434, C435 All Models 0160-5422 CAP .047uF 20%
D201-D204 All Models 1901-1087 DIODE-PWR RECT
D205, D206 All Models 1901-1214 DIODE-PWR RECT
D207, D208 All Models 1901-1098 DIODE-lN4150
D210-D212 All Models 1901-1098 DIODE-lN4150
D215 All Models 1901-1098 DIODE-lN4150
D216, D217 66101A-66103A 1901-1098 DIODE-lN4150
66104A-66106A 1901-1214 DIODE-PWR RECT
D301 66101A-66103A Not Used
66104A 1901-1383 DIODE-PWR RECT
66105A-66106A 1901-1199 DIODE-PWR RECT
D301A 66101A-66105A Not Used
66106A 1901-1199 DIODE-PWR RECT
D302 All Models 1901-1098 DIODE-lN4150
D303, D304 66101A-66103A 5060-3378 ASSY-HS, DIODE (1901-1383)
66104A 1901-1383 DIODE-PWR RECT
66105A-66106A 1901-1199 DIODE-PWR RECT
D303A, D304A 66101A-66105A Not Used
66106A 1901-1199 DIODE-PWR RECT
D314-D316 All Models 1901-1098 DIODE-lN4150
D317, D318 All Models 1901-0880 DIODE GEN PRP
D324, D325 All Models 1901-0880 DIODE GEN PRP
D326 66101A-66103A Not Used
66104A 1901-1383 DIODE-PWR RECT
66105A-66106A 1901-1199 DIODE-PWR RECT
D326A 66101A-66105A Not Used
66106A 1901-1199 DIODE-PWR RECT
Fl All Models 2110-0671 FUSE .125A 125V
F2 All Models 2110-0716 FUSE-SUBMIN .5A
F201 All Models 2110-0056 FUSE 6A 250V, CLIPS (2110-0726)
F202 All Models 2110-0716 FUSE-SUBMIN .5A
J3 All Models 1252-1152 CONNECTOR, To FRONT PANEL
J102 All Models 1252-0063 CONNECTOR, To FAN
J103 All Models 1251-8410 CONNECTOR, To MAINFRAME AC
J301 All Models 1252-0056 CONNECTOR, To BIAS BOARD
J302 All Models 1251-8676 CONNECTOR, To BIAS BOARD
K201 All Models 0490-1781 RELAY 2C 24VDC
Ll All Models 9100-1610 COIL 150nH 20%
L201 All Models 5080-2179 CHOKE-LINE
L202 All Models 5080-2180 CHOKE-INPUT
L203 All Models 9140-0137 COIL lmH 5%
L204-L211 All Models 5080-2251 BEAD-FERRITE
L301 66101A 66101-80001 CHOKE-OUTPUT
L301 66102A 66102-80001 CHOKE-OUTPUT
66103A 66103-80001 CHOKE-OUTPUT
66104A 66104-80001 CHOKE-OUTPUT
66105A 66105-80001 CHOKE-OUTPUT
66106A 66106-80001 CHOKE-OUTPUT
