16
914 mm
1067 mm
1219 mm
1067 mm
1219 mm 610 mm
2134 mm
2127 mm
ROUGH OPENING
HEIGHT TO
FINISHED
FLOORING WITH
STANDARD
279 mm GRILLE
2108 mm
MIN HEIGHT
REQUIRED TO
FINISHED
FLOORING
(LEVELERS IN)
1918
mm
178
mm
152
mm
A
ROUGH OPENING WIDTH
610 mm
ROUGH
OPENING
DEPTH
E
76
mm
457 mm
W
LOCATE WATER SUPPLY
WITHIN SHADED AREA
LOCATE ELECTRICAL
WITHIN SHADED AREA
152
mm
SHUT-OFF
VALVE
FRONT VIEW
TOP VIEW
EXTEND
WATER LINE
APPROX 914 mm
FROM BACK WALL
INSTALLATION SPECIFICATIONS
Side-by-Side Refrigerator | Freezer Models
Model I661
A) Rough Opening Width 902 mm
B) Min Door Clearance 527 mm
Model I642
A) Rough Opening Width 1054 mm
B) Min Door Clearance 649 mm
Model I685
A) Rough Opening Width 1054 mm
B) Min Door Clearance 649 mm
Model I632
A) Rough Opening Width 1206 mm
B) Min Door Clearance 743 mm
Model I695
A) Rough Opening Width 1206 mm
B) Min Door Clearance 743 mm
Dimensions are for finished rough openings.
Door swing clearances are based on
stainless steel door and handle dimensions.
OVERALL DIMENSIONS
Side-by-Side Refrigerator | Freezer Models
SIDE-BY-SIDE
Model I661
Model I642
Model I685
Ice | Water Dispensing
Model I632
Model I695
Ice | Water Dispensing
B
606 mm
BEHIND
FRAME
10 mm
FRAME
EXTENSION
90˚
Model I661
Width 914 mm
Height 2134 mm
Depth 610 mm
Model I642
Width 1067 mm
Height 2134 mm
Depth 610 mm
Model I685
Ice | Water Dispensing
Width 1067 mm
Height 2134 mm
Depth 610 mm
Model I632
Width 1219 mm
Height 2134 mm
Depth 610 mm
Illustrations shown in stainless steel design.
Model I695
Ice | Water Dispensing
Width 1219 mm
Height 2134 mm
Depth 610 mm
INSTALLATION
Refer to the
installation instruc-
tions shipped with
each Sub-Zero
product for detailed
specifications.
