OVERLAY DOOR PANEL –
MODEL UC-24B
The overlay door panel applied to the Model
UC-24B will consist of only a frame and will affix
directly to the door with screws through a series
of predrilled holes in the perimeter of the door.
The glass door opening of the Model UC-24B is
designed to be exposed to room air circulation.
Decorative overlays on the glass should be kept
to a minimum. Rails and stiles must be a
minimum of 57 mm wide. They can be increased
in size but should not exceed cabinet manufac-
turers standard width. Rails and stiles cannot
exceed the overall door panel dimensions speci-
fied in the Overlay Panel Specifications, as they
would interfere with the operation of the door.
The back sides of rails and stiles that will be
visible through the glass door will need to be
finished. Also, the inside edges of the frames
must be finished to match the front surface.
OVERLAY DOOR PANEL –
MODELS UC-24R AND UC-24C
The overlay door panel design allows for a
decorative panel to cover the door trim for a
seamless appearance that will compliment
surrounding cabinetry. You may also choose to
match the handle hardware of surrounding
cabinetry.
Refer to the Overlay Panel Specifications below
for your specific model. Illustration 1 below
applies to Models UC-24R and UC-24C. Illustra-
tion 2 applies to Model UC-24B. Outdoor Model
UC-24RO is available as a classic stainless steel
model only and comes with door panel and
handle in place.
OVERLAY PANEL SPECIFICATIONS
Undercounter Models
Models UC-24R and UC-24C
Door Panel Width 603 mm
Door Panel Height 764 mm
Panel Thickness 16 mm min
Panel Weight Limit 9 kg max
Model UC-24B
Door Panel Width 603 mm
Door Panel Height 764 mm
Width of Rails and Stiles 57 mm min
Panel Thickness 16 mm min
Panel Weight Limit 5 kg max
Illus. 1
W
H
W
H
Illus. 2
INSTALLATION
To install framed or
overlay panels, see
the detailed proce-
dures outlined in the
Sub-Zero Under-
counter Installation
Guide.
Refer to the full-
scale illustrations at
the end of this
section for specifics
on door openings
and other specifica-
tions.
