Sub-Zero Sub-Zero Freezer User Manual



48
MODEL I427
ALL WINE STORAGE
SPECIFICATIONS
Overall Width 686 mm
Overall Height 2032 mm
Overall Depth 610 mm
Wine Storage Capacity 132 bottles*
Min Height Required 2019 mm
Door Swing Clearance 648 mm
Specify Door Swing LH or RH
Shipping Wt 179 kg
FEATURES
2 Temperature Zones
9 (750 ml) Bottles per Standard Shelf
5 Top Zone Shelves (45 bottles*)
9 Bottom Zone Shelves (81 bottles*)
1 Display Shelf (6 bottles*)
Full-View Glass Door
PANEL OPTIONS
Integrated
Classic stainless steel finish
(includes handle)**
MODEL I427
MODEL I424FSMODEL I424
MODEL I424
UNDERCOUNTER
BUILT-IN
MODEL OPTIONS
Overlay Design I424/O
Classic Stainless Steel I424/S
SPECIFICATIONS
Overall Width 606 mm
Overall Height 864 mm
Overall Depth 610 mm
Wine Storage Capacity 46 bottles*
Min Height Required 870 mm
Door Swing Clearance 645 mm
Specify Door Swing LH or RH
Shipping Wt (glass) 86 kg
Shipping Wt (glass/S) 88 kg
FEATURES
2 Temperature Zones
8 (750 ml) Bottles per Standard Shelf
2 Top Zone Shelves (16 bottles*)
3 Bottom Zone Shelves (24 bottles*)
1 Fixed Bottle Holder (6 bottles*)
Full-View Glass Door
MODEL I424FS
UNDERCOUNTER
FREE-STANDING
SPECIFICATIONS
Overall Width 616 mm
Overall Height 868 mm
Overall Depth 625 mm
Wine Storage Capacity 46 bottles*
Door Swing Clearance 645 mm
Specify Door Swing LH or RH
Shipping Wt 100 kg
FEATURES
2 Temperature Zones
8 (750 ml) Bottles per Standard Shelf
2 Top Zone Shelves (16 bottles*)
3 Bottom Zone Shelves (24 bottles*)
1 Fixed Bottle Holder (6 bottles*)
Full-View Glass Door
Classic Stainless Steel Exterior
and Door Frame
