SNMP Configuration
EncrypTight User Guide 315
Traps
To configure SNMP traps, first select the trap types to be generated. All of the selected trap types will be
sent to the configured hosts. Traps cannot be configured on a per-host basis.
Table 94 Traps reported on the ETEP
Trap Description
Critical error The following critical errors traps indicate that the ETEP is in an error
state:
• criticalFailure: Traffic on the device has been halted and the device
is in a failure state.
• filesystemFailure: Inadequate free space in flash memory.
• temperatureFailure: The ETEP has exceeded the temperature
threshold for safe operation.
The following platform warning traps indicate issues that warrant
immediate attention, but do not put the ETEP in an error state:
• deployFailure: The ETEP encountered a problem while replacing its
policies.
• certificateManagementWarning: Security certificate management
encountered an issue of interest to network operators, such as
failed certificate generation, installation, or validation.
• checkSystemClockWarning: The ETEP detected clock skew that
may affect policies. System clock synchronization (NTP) should be
checked as soon as possible.
• filesystemWarning: The filesystem is approaching memory space
limits or the syslog daemon is not running.
• ntpMonitorWarning: The ETEP is unable to synchronize with an
NTP server after trying for 30 minutes.
• powerSupplyWarning: ET1000A only. The ETEP detects problems
in one of two redundant power supplies.
• rekeyFailure: The ETEP encountered a problem while rekeying
current policies.
• temperatureWarning: The operating temperature is approaching
unsafe limits. The device should be checked as soon as possible.
Generic • coldStart: the SNMP agent has been powered on.
• notifyShutdown: the SNMP agent is in the process of being shut
down.
• linkUp: one of the communication links has come up (local or
remote port).
• linkDown: one of the communication links has failed (local or
remote port).
• authenticationFailure: the SNMP agent received a packet with an
incorrect community string.
Fan • fan failed trap down: Fan failure detected. Fan is operating at less
than 75% of full speed.
• fan failed trap up: Fans are operating normally.
Log in • Reports successful and failed log in and log out attempts.
