Appendix G
Ethernet Unit Web Function
Web Function
Ethernet Units with Unit Ver. 1.3 or later can use a Web browser from a personal computer or other device to
easily make the Ethernet Unit’s system settings and monitor statuses.
Web Function List
The information displayed on the window from the Web browser for the Ethernet Unit is as follows:
Unit Setup Functions
Menu item Parameter item Corresponding CX-Programmer function
Settings CX-Programmer’s Ethernet Unit Setup window
IP address and Protocols ---
System ---
IP address Unit Setup window- Setup Tab - IP Address
Net mask Unit Setup window- Setup Tab - Sub-net Mask
FINS/UDP Port Unit Setup window- Setup Tab - FINS/UDP Port
FINS/TCP Port Unit Setup window- Setup Tab - FINS/TCP Port
Address conversion mode Unit Setup window- Setup Tab - Conversion
Auto (Dynamic) Unit Setup window- Setup Tab - Auto (dynamic)
Auto (Static) Unit Setup window- Setup Tab - Auto (Static)
Manual Unit Setup window- Setup Tab - Table used
Auto & Manual Unit Setup window- Setup Tab - Mixed
Destination IP address is changed
dynamically
Unit Setup window- Setup Tab - Destination IP Address (Change Dynamically)
Destination IP address is Not changed
dynamically
Unit Setup window- Setup Tab - Destination IP Address (Change Dynamically)
ETN11 compatible mode None
Broadcast option Unit Setup window- Setup Tab - Broadcast
Baud rate Unit Setup window- Setup Tab - Baud Rate
TCP/IP keep-alive Unit Setup window- Setup Tab - TCP/IP keep-alive
FINS/TCP Protected Unit Setup window- FINS/TCP Tab - Use IP address to protect
SMTP Server (Host name or IP
address)
Unit Setup window- SMTP Tab - Server specification type
POP Server (Host name or IP
address)
Unit Setup window- POP Tab - Server specification type
SNTP Server (Host name or IP
address)
Unit Setup window- Auto Adjust Time Tab - Server specification type
FTP Unit Setup window- Setup Tab
Login name Unit Setup window- Setup Tab - FTP (Login)
Password Unit Setup window- Setup Tab - FTP (Password)
Port No. Unit Setup window- Setup Tab - FTP (Port No.)
DNS Unit Setup window- DNS Tab
IP address of DNS server Unit Setup window- DNS Tab - IP Address
Port No. Unit Setup window- DNS Tab - Port No.
Retry timer Unit Setup window- DNS Tab - Retry timer
SMTP Unit Setup window- SMTP Tab
IP Address (or Host name) Unit Setup window- SMTP Tab - IP Address or Host name
Port No. Unit Setup window- SMTP Tab - Port No.
Local mail address Unit Setup window- SMTP Tab - Local mail address
Option (Use POP before SMTP) Unit Setup window- SMTP Tab - Use POP before SMTP
