Ethernet Unit Web Function Appendix G
Status Monitor
Web Function Password
To prevent unauthorized access to the Ethernet Unit from a Web browser, password entry is required to enable
display and setting of the parameters. Even if the password has not been set, the default password “ETHER-
NET” must be entered. To change this password, set a new password in the HTTP Tab of the CX-Program-
mer’s Unit Setup, or use the Web function and select Settings - IP address and Protocols - HTTP.
Note 1. Setting a new Web function password as soon as possible is recommended to prevent unauthorized
access.
2. The Web function can also be disabled by setting in the Web function option.
Using the Web Function (Setting Password)
The Ethernet Unit’s Web window is displayed by accessing the following URL from the Web browser.
URL: http://(Ethernet Unit’s IP address)/0
Use the following procedure to set the Unit’s system settings (HTTP password setting in this example) using
Internet Explorer version 6.0 and the Ethernet Unit’s Web function.
Receive Mail Unit Setup window- Receive Mail Tab
Mail Address Protection Setting Unit Setup window- Receive Mail Tab - Protect using mail address
Attached File Enable Settings Unit Setup window- Receive Mail Tab - Receive file with specified extension only
Command Enable Setting Unit Setup window- Receive Mail Tab - Receive specified commands only
Menu item Corresponding CX-Programmer function
Status View ---
Unit information FINS(0501): CONTROLLER DATA READ
Unit status FINS(0601): CONTROLLER STATUS READ
Protocol status ---
IP status FINS(2762): PROTOCOL STATUS READ, IP status
ICMP status FINS(2762): PROTOCOL STATUS READ, ICMP status
TCP status FINS(2762): PROTOCOL STATUS READ, TCP status
UDP status FINS(2762): PROTOCOL STATUS READ, UDP status
Memory status FINS(2763): MEMORY STATUS READ
Socket status FINS(2764): SOCKET STATUS READ
Fins status Ethernet Unit’s internal node table
Mail log RECEIVE MAIL: READ MAIL LOG
Error log FINS(2102): READ ERROR LOG
Send mail status Mail send status 1 to 8
Menu item Parameter item Corresponding CX-Programmer function
