1-5
Getting Started
Step 2. Connect the Line-Power Cable
Step 2. Connect the Line- Power Cable
WARNING This is a Safety Class I Product (provided with protective earth). The
mains plug shall only be inserted in a socket outlet provided with a
protective earth contact. Any interruption of the protective conductor
inside or outside of the instrument is likely to make the instrument
dangerous. Intentional interruption is prohibited.
CAUTION Always use the three-prong AC power cord supplied with this instrument.
Failure to ensure adequate earth grounding by not using this cord may cause
instrument damage.
CAUTION Do not connect ac power until you have verified the line voltage is correct as
described in the following paragraphs. Damage to the equipment could result.
CAUTION This instrument has autoranging line voltage input. Be sure the supply voltage
is within the specified range.
1 Verify that the line power meets the requirements shown in the
following table.
2 Connect the line-power cord to the instrument’s rear-panel connector.
Line Power Requirements
Power: max. 70 W
Voltage: max: 110 / 115 / 230 / 240 V~
Frequency 50 / 60 Hz
