Programmer’s Guide, cont’d
MTPX Plus Twisted Pair Matrix Switchers • Programmer’s Guide
4-20
Command/response table for SIS commands (continued)
Command ASCII command
(host to switcher)
Response
(switcher to host)
Additional
description
View ties, gain, volume, mutes, presets, and DIP switch status (continued)
View audio global preset
configuration
EX2)
*
X@
*2VC
} X!
n
•
X!
n+1
•...•
X!
n+15
•Aud
]
Show preset
X2)
’s audio
configuration. Show the
inputtiedto16sequential
outputs, starting from output
X@
.
Command description:
Responsedescription:
preset #*starting output # (StO#)*2(=audio)VC
input#(I#)tiedtoStO#•I#tiedtoStO#+1•I#tiedtoStO#+2•...•I#tiedtoStO#15•Aud
]
N
The starting output number (
X@
)shouldalwaysbe“1”formatrixsizesof16outputsorsmaller.
N
EX2)
*1*2VC
}
where
X2)
=0returnstheswitcher’scurrentaudioconguration.
Example:
(MTPX Plus 1632)
E
15*17*2VC
}
17Output:
Response = tied input:
i
nput 1 t
i
e
d
to output 3
18 19 20 21 22 23 24
01•01•01•01•02•12•12•00•00•00•00•00•01•08•15•16•Aud
25 26 27 28 29 30 31 32
no t
i
e
d
i
nput
Each position shown in the response is an output: left = starting output (17), right =
startingoutput+15(32).Thenumberineachpositionistheinputtiedtothatoutput.
Inthisexample,preset15,audioinput1istiedtooutputs17,18,19,20,and29;input2is
tiedtooutput21;input12istiedtooutputs22and23;input8istiedtooutput30;input
15istiedtooutput31;andinput16istiedtooutput32.Noinputistiedtooutput24,25,
26,27,and28.
View video room preset
configuration
EX2@
*
X2)
*1*1VC
} X!
n
•
X!
n+1
•...•
X!
n+15
•Vid
]
Show room
X2@
, preset
X2)
’s
video configuration. Show
theinputtiedtoupto16
outputs assigned to room
X2@
.
Command description:
Responsedescription:
room #*room preset #*starting output # (StO#)*1(=video)VC
input#(I#)tiedtoStO•I#tiedtoStO#+1•I#tiedtoStO#+2•...•I#tiedtoStO#+15•Vid
]
N
The starting output number (
X@
)shouldalwaysbe“1”formatrixsizesof16outputsorsmaller.
View audio room preset
configuration
EX2@
*
X2)
*1*2VC
} X!
n
•
X!
n+1
•...•
X!
n+15
•Aud
]
Show room
X2@
, preset
X2)
’s
audio configuration. Show
theinputtiedtoupto16
outputs assigned to room
X2@
.
Command description:
Responsedescription:
room #*room preset #*starting output # (StO#)*2(=audio)VC
input#(I#)tiedtoStO•I#tiedtoStO#+1•I#tiedtoStO#+2•...•I#tiedtoStO#+15•Aud
]
N
The starting output number (
X@
)shouldalwaysbe“1”formatrixsizesof16outputsorsmaller.
N
X2)
= Global or room preset # 0 - 32, 10 maximum for a room preset (0 = current configuration)
X@
= Output number 01 – 32
X!
= Input number
00 – (maximum number of inputs for your model)
X2@
= Room # (for room presets) 10 max. (each can have up to 10 presets (
X2)
s) assigned)
