2-7
MTPX Plus Twisted Pair Matrix Switchers • Installation
N
• Matrixsizes1616andsmallerhaveonelocalvideooutput.
Matrixsizes1632andlargerhavetwolocalvideooutputs.
•
Theseoutputsarealwaysoutputs1and2,withthesameinputstiedtothem
astoTPoutputs1and2.
•
The video that is output on this (these) connector(s) is converted from the tied
proprietaryTPinputsignalorthelocal(VGA)input.Thisfeatureallows
youduplicatesofoutput(s)1(and2)whileeliminatingtheneedforextra
receivers.
•
Extron recommends againsttyingalocal(VGA)inputtoalocal(VGA)
output;theimagedisplayedfromsuchatiemaybeoverpeaked.
•
Wheneithertheoutputorinputofatieislocal(VGA),Extronrecommends
thattheMTP
inputoroutputbeconnectedbyaminimumof50’(15m)of
TP cable
to prevent o
verpeaking.
• ThisconnectorcanalsooutputHDcomponentvideo,componentvideo,
S-video, or composite video if that is the video format that was input.
IfthevideooutputisNTSCcomponentvideo,S-video,orcompositevideo,
set the output to turn off sync stripping. See the Local video output
sync polarity SIScommandsonpage4-13.
h
Mono Audio (local audio) outputs — Connect audio devices, such as an
audio amplifier or powered speakers, to these four or eight 3.5 mm, 5-pole
captive screw connectors. These connectors output the selected unamplified,
monolinelevelaudio.Seegure2-8towireanoutputconnector.Usethe
supplied tie-wrap to strap the audio cable to the extended tail of the connector.
Mono Output
L R
Do not tin the wires!
Ring
Sleeve(s)
Tip
Tip
Ring
Figure 2-8 — Captive screw connector wiring for audio output
C
Connectthesleevetoground(Gnd).Connectingthesleevetoa
negative (-) terminal will damage the audio output circuits.
C
The length of the exposed (stripped) portion of the copper wires is
important. The ideal length is 3/16” (5 mm). Longer bare wires can
short together. Shorter bare wires are not as secure in the direct insertion
connectors and could be pulled out.
N
• Matrixsizes1616andsmallerhavefourlocalaudiooutputs.
Matrixsizes1632andlargerhaveeightlocalaudiooutputs.
•
Theseoutputsarealwaysoutputs1through4(or8),withthesameinputs
tiedtothemastoTPoutputs1through4(or8).
•
The audio that is output on this (these) connector(s) is converted from the
tied proprietary TP input signal or the local audio input. This feature allows
you duplicates of the outputs while eliminating the need for extra receivers.
• WhenaninputthatisconguredasRS-232isswitchedtoalocalaudio
output,theoutputismutedtopreventRS-232noiseontheaudiooutput.
The volume level for each local output can be individually set via the
front panel or serial port control. See chapter 3, “Operation”, chapter 4,
“Programmer’sGuide”,chapter5,“MatrixSoftware”,andchapter6,
“HTML Operation”, for details.
