Operation, cont’d
MTPX Plus Twisted Pair Matrix Switchers • Operation
3-28
Using presets
The current configuration (configuration 0) can be saved as a preset in any one
of 32 preset memory addresses. All 32 presets are assigned to the input buttons
and output buttons and are available to be either saved or retrieved from the
front panel. When a preset is retrieved from memory, it becomes the current
configuration.
N • Onlytheaudioandvideotiesarestoredandrecalled;audiogainsettingsare
not saved, and they do not change when a preset is recalled.
• Presetscannot be viewed from the front panel unless recalled as the current
configuration. Presets canbeviewedusingExtron’sWindows-basedcontrol
program.Seechapter5,“MatrixSoftware”,formoredetails.
• Thecurrentcongurationandallpresetsarestoredinnon-volatilememory.
When power is removed and restored, the current configuration is still active
and all presets are retained.
• Whenapresetisrecalled,itreplacesthecurrentconguration,whichislost
unless it is also stored as a preset. The recalled preset overwrites all of the
current configuration ties in favor of the preset configuration ties.
• Figure3-36showsthepresetsassociatedwiththetwoinputandoutput
button configurations for the MTPX Plus matrix switchers.
I
N
P
U
T
S
1
16 x 32, 32 x 16, and 32 x 32 matrix sizes
Input
buttons
Input
buttons
Output
buttons
Preset
1
8 x 16, 16 x 8, and 16 x 16 matrix sizes
Preset
1
Preset
6
Preset
7
Preset
10
Preset
15
Preset
16
Preset
11
Preset
3
Preset
8
Preset
9
Preset
4
Preset
5
Preset
13
Preset
14
Preset
12
Preset
2
Preset
17
Preset
22
Preset
23
Preset
26
Preset
31
Preset
32
Preset
27
Preset
19
Preset
24
Preset
25
Preset
20
Preset
21
Preset
29
Preset
30
Preset
28
Preset
18
Preset
5
Preset
6
Preset
10
Preset
7
Preset
13
Preset
14
Preset
15
Preset
2
Preset
8
Preset
9
Preset
3
Preset
4
Preset
11
Preset
12
Preset
16
Preset
17
Preset
21
Preset
22
Preset
26
Preset
23
Preset
29
Preset
30
Preset
31
Preset
18
Preset
24
Preset
25
Preset
19
Preset
20
Preset
27
Preset
28
Preset
32
2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
INPUTS
1
2
3 4
5
6
7
8
9
10
11
12
14
15
16
13
1
2
3
4
5
6
7
8
9
10
11
12
14
15
16
13
OUTPUTS
Figure 3-36 — Preset locations
