4-23
MTPX Plus Twisted Pair Matrix Switchers • Programmer’s Guide
Command/Response Table for IP-specific SIS Commands
Symbol definitions
X4)
= Matrix name (Up to 240 alphanumeric characters)
N
Thefollowingcharactersareinvalidinthename:{space}~,@=`[]{}<>‘“;:|\and?.
X4!
= Default name MTPX- +last3pairsofMACaddress
X4@
= Timeanddate(forset) Intheformat:MM/DD/YY•HH:MM:SS where:
MM = month: 01 (January) through 12 (December)
DD = 01 through 31
YY = 00 through 99
HH = 00 through 23
MM = 00 through 59
SS = 00 through 59
X4#
= Timeanddate(forread) Intheformat:Day,•DD•Mmm•YYYY•HH:MM:SS where:
Day of the week: Mon through Sun
DD = 01 through 31
Mmm = month: Jan through Dec
YYYY = 2000 through 2099
HH = 00 through 23
MM = 00 through 59
SS = 00 through 59
X4$
= GMToffset –12.0through+14.0.HoursandminutesremovedfromGMT
X4%
= Daylight Savings Time 0 = Daylight Savings Time off/ignore
1 = Daylight Savings Time on (northern hemisphere)
2 = Daylight Savings Time on (Europe)
3 = Daylight Savings Time on (Brazil)
X4^
= IP address ###.###.###.###
X4&
= Hardware (MAC) address ##-##-##-##-##-##
X4*
= Number of open connections 0 - 255
X4(
= Password Up to 12 alphanumeric characters
N
Thefollowingcharactersareinvalidinpasswords:{space}+~,@=`[]{}<>‘“;:|\and?.
X5)
= Domain name Standard domain name rules apply (for example: xxx.com)
N
Thefollowingcharactersareinvalidinadomainname:{space}+~,=`[]{}<>‘“;:|\and?.The@characterisacceptableonlyas
the lead-in to the domain name (such as @extron.com).
X5!
= E-mailaccount 65-72.65=e-mailrecipient1,66=2,67=3,...72=recipient#8
X5@
= E-mail address Typical e-mail address format (for example: nnnn@xxx.com)
X5#
= Notifywhen? 0=noresponse 3=both1&2
1 = fail/missing 4 = suspend
2 = fixed/restored
X5$
= Notification selections 00 = both fans, 01 (fan 1), or 02 (fan 2)
X5%
= Notify status (for read) 17-digit number. For each digit: 0 = do not notify, 1 = notify
X5^
= DHCP 0 =1 off, 1 = on
X5&
= Port # 00 through 99 (00 = all ports)
X5*
= Baudrate 9600,19200,38400,115200
X5(
= Parity odd, even, none, mark, space (only the first letter required)
X6)
= Databits 7,8
X6!
= Stop bits 1, 2
X6@
= Port type 0 = RS-232
1 = RS-422
2=RS-485
X6#
= Verbose mode 0 = clear/none (default for Telnet connection)
1 = verbose mode (default for RS-232/RS-422 connection)
2 = tagged responses for queries
3 = verbose mode and tagged for queries
N
Iftaggedresponsesisenabled(modes2and3),allreadcommandsreturntheconstantstringandthevalueasthesetcommanddoes
(for example, the read matrix name command
E
CN
}
,returnsIpn•
X4)]
).
X6$
= Flow control hardware, software, none (only the first letter required)
X6%
= Data pacing (in ms between bytes) 0000 (default) - 1000
