MTPX Plus Twisted Pair Matrix Switchers • Reference Information

Male-to-male VGA molded connector cables Part number

VGA M-M MD/3, 3' (0.9 m) 26-238-14

VGAM-MMD/6,6'(1.8m) 26-238-01

VGA M-M MD/10, 10' (3.0 m) 26-238-07

VGA M-M MD/15, 15' (4.5 m) 26-238-02

VGAM-MMD/25,25'(7.6m) 26-238-03

VGAM-MMD/35,35'(10.6m) 26-238-17

VGA M-M MD/50, 50' (15.2 m) 26-238-18

VGAM-MMD/75,75'(22.8m) 26-238-19

VGA M-M MD/100, 100' (30.4 m) 26-238-20

Male-to-male VGA molded connector cables Part number

VGA M-M BK/3, 3' (0.9 m) 26-238-24

VGAM-MBK/6,6'(1.8m) 26-238-25

VGA M-M BK/10, 10' (3.0 m) 26-238-26

VGA M-M BK/15, 15' (4.5 m) 26-238-27

VGAM-MBK/25,25'(7.6m) 26-238-28

VGAM-MBK/35,35'(10.6m) 26-238-16

VGA M-M BK/50, 50' (15.2 m) 26-238-04

VGAM-MBK/75,75'(22.8m) 26-238-05

VGA M-M BK/100, 100' (30.4 m) 26-238-06

Connectors

Connector Part number

CAT6jack(black),qty.10 100-476-01

CAT6jack(red),qty.10 100-477-01

CAT6jack(blue),qty.10 100-478-01

CAT6jack(orange),qty.10 100-479-01

CAT6jack(gray),qty.10 100-480-01

CAT6jack(white),qty.10 100-481-01

CAT6jack(ivory),qty.10 100-482-01
