B-5

MTPX Plus Twisted Pair Matrix Switchers • Reference Information

DIM weight (International)

1632,3216,3232models .... 26lbs(11.8kg)

816,168,1616models ........ 18lbs(9kg)

Vibration ......................................... ISTA 1A in carton (International Safe Transit Association)

Regulatory compliance

Safety ................................... CE, C-tick, CUL, UL

EMI/EMC .......................... CE, C-tick, FCC Class A, ICES, VCCI

Environmental ................... Complies with the appropriate requirements of WEEE.

MTBF ............................................... 30,000 hours

Warranty ......................................... 3 years parts and labor

N

 Allnominallevelsareat±10%.

N

Speciﬁcations are subject to change without notice.

Part Numbers and Accessories

MTPX Plus matrix switcher part numbers

Matrix switcher part numbers Part number

MTPXPlus816 60-834-01

MTPXPlus168 60-833-01

MTPXPlus1616 60-832-01

MTPXPlus1632 60-898-01

MTPXPlus3216 60-899-01

MTPX Plus 3232 60-897-01

Included parts

These items are included in each order for a MTPX Plus matrix switcher:

Included parts Replacement part

number

Tweeker (small screwdriver)

MTPXPlusUser’sManual

5-pole captive screw audio connectors

(7 or 14, depending on the model)

3-pole captive screw connectors

(8or16,dependingonthemodel)

Extron Software Products CD

(Matrix Switchers Control Program and

Button-Label Generator)
