3-27
MTPX Plus Twisted Pair Matrix Switchers • Operation
7. Simultaneously press and release the Video button and Audio button
(figure 3-35). The switcher exits I/OGroup mode.
N
 Ifyoudonothingforapproximately30seconds,thefrontpaneltimesoutandthe
switcher exits I/O Group mode.
• Group1consistsofinputs1through4andoutputs1through4.
• Group2consistsofinputs5through8andoutputs5through8.
I / O
VIDEO AUDIO
Simultaneously, press and
release both buttons.
Figure 3-35 — Deselect I/O Group mode
