Introduction, cont’d
MTPX Plus Twisted Pair Matrix Switchers • Introduction
1-6
Recommended maximum TP transmission distances at 60 Hz, —
transmitter to receiver using MTPX TP inputs and outputs
INPUT
AUDIO
MONITOR
POWER
12V
.5A MAX
OUTPUT
MTP T 15HD A
PRE-PEAK
ON
OFF
ETHERNET
ACT
INPUT
SELECT
LOCAL
RJ-45
LOCAL INPUTS
12345678910111213141516
17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
12345678910111213141516
17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
1
2
213
456
RS-232 OUTPUT INSERTION
LOCAL OUTPUTS OUTPUTS
INPUTS
CONTROL
MONO AUDIO OUTPUTSAUDIO INPUTS
LINK
RESET
LR
1
LR
2
LR
3
LR
4
LR
5
LR
6
LR
1
LR
2
LR
3
LR
4
LR
5
LR
6
LR
7
LR
8
TxRx
1
TxRx
2
TxRx
3
TxRx
4
TxRx
5
TxRx
6
TxRx
7
TxRx
8
TxRx
9
TxRx
10
TxRx
11
TxRx
12
TxRx
13
TxRx
14
TxRx
15
TxRx
16
US
LISTED
1T23
I.T.E.
®
3.2A MAX
INPUT
RGB
POWER
12V
0.5A MAX
VID
Y/C
OUTPUTS
MTP U R A
1
MONO AUDIO
2
3
4
MTP Transmitter
MTP Receiver
Video
format
MTPX Pre-Peak Maximum distance
High quality Variable quality
Off On MTPX
input
c
MTPX
output
d
MTPX
input
c
MTPX
output
d
Component,
S-video
<300'
(90 m)
>350'
(105 m)
700'
(215 m)
700'
(215 m)
700'
(215 m)
800'
(245 m)
Composite
<300'
(90 m)
>350'
(105 m)
700'
(215 m)
700'
(215 m)
750'
(230 m)
750'
(230 m)
640 x 480
<300'
(90 m)
>350'
(105 m)
550'
(170 m)
600'
(185m)
550'
(170 m)
700'
(215 m)
800 x 600
<300'
(90 m)
>350'
(105 m)
500'
(150 m)
500'
(150 m)
600'
(185m)
600'
(185m)
1024 x 768*
<300'
(90 m)
>350'
(105 m)
450'
(135 m)
450'
(135 m)
550'
(170 m)
550'
(170 m)
1280 x 960*
<300'
(90 m)
>350'
(105 m)
350'
(105 m)
350'
(105 m)
450'
(135 m)
450'
(135 m)
1280 x 1024*
<250'
(75 m)
>300'
(90 m)
350'
(105 m)
350'
(105 m)
450'
(135 m)
450'
(135 m)
1360 x 765
<250'
(75 m)
>300'
(90 m)
350'
(105 m)
350'
(105 m)
500'
(150 m)
500'
(150 m)
1365 x 768
<250'
(75 m)
>300'
(90 m)
350'
(105 m)
350'
(105 m)
450'
(135 m)
450'
(135 m)
1366 x 768
<250'
(75 m)
>300'
(90 m)
350'
(105 m)
350'
(105 m)
450'
(135 m)
450'
(135 m)
1440 x 900
<250'
(75 m)
>300'
(90 m)
350'
(105 m)
300'
(90 m)
400'
(120 m)
400'
(120 m)
1400 x 1050
<250'
(75 m)
>300'
(90 m)
350'
(105 m)
300'
(90 m)
400'
(120 m)
400'
(120 m)
1600 x 1200*
<250'
(75 m)
>300'
(90 m)
300'
(90 m)
300'
(90 m)
450'
(135 m)
450'
(135 m)
1920 x 1200
<250'
(75 m)
>300'
(90 m)
300'
(90 m)
250'
(75 m)
400'
(120 m)
400'
(120 m)
HDTV 720p
<250'
(75 m)
>300'
(90 m)
400'
(120 m)
400'
(120 m)
500'
(150 m)
500'
(150 m)
HDTV 1080i
<250'
(75 m)
>300'
(90 m)
300'
(90 m)
250'
(75 m)
400'
(120 m)
400'
(120 m)
HDTV 1080p
<250'
(75 m)
>300'
(90 m)
300'
(90 m)
250'
(75 m)
400'
(120 m)
400'
(120 m)
N
Resolutionsmarkedwithanasterisk(*)inthistablehavethesamerange
specicationsat75Hz.
