Matrix Software, cont’d
MTPX Plus Twisted Pair Matrix Switchers • Matrix Software
5-10
Mail Server IP Address field
The Mail Server IP Address field displays the IP address of the mail server that
handles the e-mail for the facility in which the MTPX Plus switcher is installed.
Valid IP addresses consist of four 1-, 2-, or 3-digit numeric octets separated by dots
(periods). Each field can be numbered from 000 through 255. Leading zeroes, up to
threedigitstotalpereld,areoptional.Valuesof256andaboveareinvalid.
Edit this field as follows:
1. Click in the mail server IP address field. The graphic cursor becomes a text
cursor.
2. Edit the IP address as desired.
3. Press the Tab key on the keyboard or click in another field to exit the mail
server IP address field.
4. Click the Take button to make the address change take affect.
Mail Server Domain Name field
The Mail Server Domain Name field displays the domain name that the MTPX Plus
switcher uses to log on to the e-mail server. Standard domain conventions (such as
xxx.com) apply.
N
The following characters are invalid in a domain name:
{space}+~,=‘[]{}<>’“;:|\and?.The@characterisonly
acceptable as the lead-in to the domain name (such as @folklore.net).
Edit this field as follows:
1. Click in the Mail Server Domain Name field. The graphic cursor becomes a
text cursor.
2. Edit the name as desired.
3. Press the Tab key on the keyboard or click in another field to exit the Mail
Server Domain Name field.
4. Click the Take button to make the name change take affect.
E-mail Addressee fields
The eight E-mail Addressee fields permit the administrator to identify the e-mail
addresses of the personnel to whom the MTPX Plus switcher e-mails notification of
itsfailureandrepairstatus.Figure5-8showsatypicale-mailfromtheswitcher.
Miles Standish
From: MTPX-FF-FF-09@folklore.net
Sent: Tuesday, June 10, 2008 10:05 AM
To: Miles Standish
Subject: MTPX-FF-FF-09 - Fan Failure
Tue, 10 Jun 2008 10:05:07
Unit Name = MTPX-FF-FF-09
Unit IP Address = 192-168-254-254
Figure 5-8 — Typical MTPX Plus e-mail
The radio buttons and check boxes associated with each address field permit the
administrator to specify specific e-mail requirements for each recipient.
