REF 1057983 A Respironics V200 Ventilator Operator’s Manual Appendix C-1
Appendix C. Alarm Testing Procedure
The following procedure is available if the operator wants to test the operation
of the following alarms. We recommend following “Preoperational Procedure”
on page 8-32 before performing the Alarm Testing procedure. It is assumed
that the preoperational procedure has been run before the Alarm Testing
Procedure is followed.
Setup
1. Connect O
2
supply to the Respironics V200 Ventilator.
2. Connect optional O
2
sensor.
3. Run EST.
4. Attach the test lung to the patient wye. (Use the test lung provided
with your system.)
5. Use the following settings:
• Mode VCV-A/C
• Tidal Vol: 400ml
• High Pressure (HIP): 50cmH
2
0 (hPa)
(or higher if required by the test lung)
• Rate: 10 Bpm
• Low Insp Press: 3 cmH
2
0 (hPa)
• Peak Flow 40 Lpm
• PEEP: 4 cmH
2
0 (hPa)
• Low PEEP: 2 cmH
2
0 (hPa)
• Low Vt Mand: 0 mL
• PSV: 0 cmH
2
0 (hPa)
• Low Vt Spont: 0 Lpm
• I-Trigger: 2 cmH
2
0 (hPa)
• High Rate: 150 Bpm
•O
2
: 21%
• Low VE: 1 L
• Insp. Hold: 0 sec.
• Apnea: 15 sec.
• Apnea Rate: 20 Bpm
