SIS
Programming and Control, cont’d
ISS 506 Integration Seamless Switcher • SIS
Programming and Control
4-28
Command ASCII (Telnet)
(host to switcher)
URL Encoded (Web)
(host to switcher)
Response
(switcher to host)
Additional description
PIP window vertical shift
Set a specific vertical position
3*
X1&
/ 3*
X1&
/ 3Vph
X1&]
Specify the vertical position of the PIP window.
Increment 3+/ 3+/
3Vph
X1&]
Shift the PIP window down one line.
Decrement 3-/ 3-/
3Vph
X1&]
Shift the PIP window up one line.
View vertical position 3/ 3/
X1&]
View the PIP window’s position setting.
PIP window horizontal size
Set a specific horizontal size
3*
X1^
: 3*
X1^
:
3Hsz
X1^]
Set the PIP window’s horizontal width to
X1^
.
Increment horizontal size
3+: 3+:
3Hsz
X1^]
Make the PIP window one pixel wider.
Decrement horizontal size
3-
: 3-:
3Hsz
X1^]
Make the PIP window one pixel narrower.
View the horizontal size value
3
: 3:
X1^]
Show the horizontal size of the PIP window.
PIP window vertical size
Set a specific vertical size
3*
X1^
; 3*
X1^
;
3Vsz
X1^]
Set the PIP window’s vertical height to
X1^
.
Increment vertical size
3+
; 3+;
3Vsz
X1^]
Make the PIP window one pixel taller.
Decrement vertical size
3-
; 3-;
3Vsz
X1^]
Make the PIP window one pixel shorter.
View the vertical size value
3
; 3;
X1^]
Show the vertical size of the PIP window.
PIP image horizontal shift
Set a specific horizontal position
4*
X1&
H 4*
X1&
H 4Hph
X1&]
Specify the horizontal position of the PIP image
within the window.
Increment 4+H 4+H
4Hph
X1&]
Shift the PIP image down one line.
Decrement 4-H 4-H
4Hph
X1&]
Shift the PIP image up one line.
View horizontal position 4H 4H
X1&]
View the PIP image’s position setting.
PIP image vertical shift
Set a specific vertical position
4*
X1&
/ 4*
X1&
/ 4Vph
X1&]
Specify the vertical position of the PIP image
within the window.
Increment 4+/ 4+/
4Vph
X1&]
Shift the PIP image down one line.
Decrement 4-/ 4-/
4Vph
X1&]
Shift the PIP image up one line.
View vertical position 4/ 4/
X1&]
View the PIP image’s position setting.
Command/response table for SIS commands (continued)
N
X1^
= Size Up to 4095
X1&
= Position value Up to 4095
