4-13
ISS 506 Integration Seamless Switcher • SIS
Programming and Control
Command/response table for SIS commands (continued)Command/response table for SIS commands (continued)
Command ASCII (Telnet)
(host to switcher)
URL Encoded (Web)
(host to switcher)
Response
(switcher to host)
Additional description
Wipe effect, duration, and subeffect
N
The “n” variable in the wipe effect and wipe subeffect and duration responses below has no meaning.
Although they look similar, the set wipe effect command (4*2*#) and set dissolve subeffect and duration command (4*2*
X#
*
X%
#) must be sent separately for them to make the
desired change.
Set the wipe effect 4*2*# 4*2*#
Eff2*
X#
*
X%
*1*n
]
Set the switch effect to wipe for “take” operations.
Set wipe duration and subeffect
4*2*
X#
*
X%
# 4*2*
X#
*
X%
# Eff2*
X#
*
X%
*
X$
*n
]
Set the wipe duration to
X#
, and set the
subeffect to
X%
.
N
The set wipe duration and subeffect command (4*2*
X#
#) must include the leading “2” variable to specify that the
X#
and
X%
values are to be applied to the wipe effect.
If a different effect is selected (an effect button other than Wipe is lit on the front panel), this command sets the duration and subeffect, but does not select the wipe effect.
An
X%
variable of 00 (cut) or 01 (dissolve) is an invalid value for the wipe subeffect.
Example:
4*2*15*8# 4*1*15*8#
Eff2*015*008*0*n
]
Set the wipe switching duration to 1.5 seconds
and the subeffect to soft curtain in. In this
example, the “0” in the response indicates that
wipe is not the selected effect.
View wipe effect status 4*2# 4*2#
X#
*
X%
*
X$
*n
]
Title effect and title key threshold
N
The “nnn” variable in the title key effect and duration responses below has no meaning.
Although they look similar, the set title effect command (4*3*#) and set threshold command (4*3*
X#
*
X%
#) must be sent separately for them to make the desired change.
Set the title effect 4*3*# 4*3*#
Eff3*
X^
*nnn*1*
X&]
Select the title effect for “cut” and “take”
operations.
Set the title key threshold
4*3*
X^
# 4*3*
X^
# Eff3*
X^
*nnn*
X$
*
X&]
Set the title key threshold to
X^
.
N
The set title key threshold command (4*3*
X^
#) must include the leading “3” variable to specify that the
X^
value is to be applied to the title effect.
If a different effect is selected (an effect button other than Title is lit on the front panel), this command sets the threshold, but does not select the title effect.
Example:
4*3*177# 4*3*177#
Eff3*177*nnn*1*1
]
Set the title key threshold to 177. In this example’s
response, “1*1” indicates that the title effect is set
and the title is displayed on the program output.
View title effect status 4*3# 4*3#
X^
*nnn*
X$
*
X&]
N
X#
= Effect duration 00 – 50 (5.0 seconds in 0.1-second increments)
X$
= Effect status 1 = selected 2 = deselected
X%
= Subeffect: 00 = Cut (PIP) 01 = Dissolve (PIP) 02 = Soft right 03 = Soft left 04 = Soft up
05 = Soft down 06 = Soft center in 07 = Soft center out 08 = Soft curtain in 09 = Soft curtain out
10 = Soft square in 11 = Soft square out 13 = Soft plus out 12 = Soft plus in 14 = Hard right
15 = Hard left 16 = Hard up 17 = Hard down 18 = Hard center in 19 = Hard center out
20 = Hard curtain in 21 = Hard curtain out 22 = Hard square in 23 = Hard square out 24 = Hard plus in
25 = Hard plus out
X^
= Luma and color key level 000 – 255
X&
= PIP or title status 0 = off (not displayed) 1 = on (displayed)
