SIS
Programming and Control, cont’d
ISS 506 Integration Seamless Switcher • SIS
Programming and Control
4-26
Command/response table for SIS commands (continued)
Command ASCII (Telnet)
(host to switcher)
URL Encoded (Web)
(host to switcher)
Response
(switcher to host)
Additional description
Image recall (continued)
Assign black screen to the Logo 2
buttons
E
2*
•
RF
}
W2•*RF
|
Imr2*
]
Assign a black screen to the front panel
Program Logo 2 and Preview Logo 2 buttons.
View the logo button setting
EX3%
RF
}
W
X3%
RF
| X3$]
N
If a black fill is assigned to a logo button,
X3$
isreplacedwith•.
Logo on/off
Logo on
39*
X@
*
X3%
*1# 39*
X@
*
X3%
*1#
X@
Lbu
X3%
*1
]
Display logo
X3%
on the
X@
output. The front
panel logo button lights.
Example:
39*1*1*1# 39*1*1*1#
1Lbu1*1
]
Display logo 1 on the program output.
Logo off
39*
X@
*
X3%
*0# 39*
X@
*
X3%
*0#
X@
Lbu
X3%
*0
]
Do not display logo
X3%
on the
X@
output. The
front panel logo button goes out.
View logo on/off status
39*
X@
*
X3%
# 39*
X@
*
X3%
#
X1%]
Logo image key type
Set key type
32*
X3%
*
X3^
# 32*
X3%
*
X3^
# Ktp
X3%
*
X3^]
Set the key type for the logo assigned to logo
button
X3%
to
X3^
.
View key type
32*
X3%
# 32*
X3%
#
X3^]
Logo image color and luma key levels
N
When the ISS receives three
X^
values in the set logo image recall command (35#), it interprets the command as “set color (RGB) level”. When the ISS receives only one
X^
value, it interprets the command as “set luma level”. The ISS always returns all four (luma and RGB)
X^
values.
Set color key level
35*
X3%
*
X^
*
X^
*
X^
# 35*
X3%
*
X^
*
X^
*
X^
# Klv
X3%
*
X^
*
X^
*
X^
*
X^]
Set the color key level for the logo assigned
t o button
X3%
to
X^
,
X^
, and
X^
(in RGB
order). The
X^
response values are in
“luma*red*green*blue order.
Set luma key level
35*
X3%
*
X^
# 35*
X3%
*
X^
# Klv
X3%
*
X^
*
X^
*
X^
*
X^]
Set the luma key level for the logo assigned to
button
X3%
to
X^
. The
X^
response values are
in “luma*red*green*blue order.
View level
35*
X3%
# 35*
X3%
#
X^
*
X^
*
X^
*
X^]
The
X^
response values are in
“luma*red*green*blue order.
Command/response table for SIS commands (continued)
N
X@
= Output number 1 = Program 2 = Preview 3 = PIP window 4 = PIP image
X^
= Luma and color key level 000 – 255
X1%
= Logo status 0 = log off 1 = logo on
X3$
= Logo file name nnn.bmp (up to 16 alphanumeric characters , which must include “.bmp” file extension). Blank (space bar) = black screen
X3%
= Logo name 1 or 2
X3^
= Logo recall key type 0 = level 1 = color
