SIS
Programming and Control, cont’d
ISS 506 Integration Seamless Switcher • SIS
Programming and Control
4-8
Cutting or dissolving in swap mode
The switcher issues the following reports when you swap the preview and program
outputs in stay mode:
Tke1*
X*
] The switcher has received the front panel
Take command.
Bsy1]
The switcher is performing the selected
effect (wipe or dissolve).
Reconfig1]
The input to the program output has
changed (to the input that had been
switched to preview output).
Reconfig2]
The input to the preview output has
changed (to the input that had been
switched to program output).
Bsy0]
The switcher is finished performing the
selected effect (wipe or dissolve).
Switching in a PIP window or title
The switcher issues the following reports when you switch a title or a PIP window
on:
Tke1*
X*
] The switcher has received the front panel
Take command.
Bsy1]
The switcher is performing the selected
effect (PIP or title).
The switcher issues the following reports when you switch a title or a PIP window
off:
Bsy1]
The switcher is still performing the selected
effect (PIP or title).
Bsy0]
The switcher has turned off the selected
effect (PIP or title).
Input and output video type
X!
Typ
X1)
]
A front panel input video type selection has occurred.
X!
is the input number and
X1)
is the input video type.
Rte
X1!X1@
]
A front panel output video format selection has occurred.
X1!
is the output
resolution and
X1@
is the output refresh rate.
Syn
X1#
]
A front panel output video type selection has occurred.
X1#
is the output video
format (RGBHV or RGBS).
Pol
X1$
]
A front panel output video polarity selection has occurred.
X1$
is the output sync
polarity.
