Programming and Control, cont’d
ISS 506 Integration Seamless Switcher • SIS
Programming and Control
4-16
Command/response table for SIS commands (continued)
Command ASCII (Telnet)
(host to switcher)
URL Encoded (Web)
(host to switcher)
Response
(switcher to host)
Additional description
View selected input
View selected video and audio
input
X@
!
X@
!
X!]
Input
X!
video and audio are selected for the
X@
output.
View selected video input
X@
&
X@
&
X!]
Input
X!
video is selected for the
X@
output.
View selected audio input
X@
$
X@
$
X!]
Input
X!
audio is selected for the
X@
output.
Input video type
Set input video type
X!
*
X1)
\
X!
*
X1)
\ Typ
X!
*
X1)]
Specify input
X!
video type.
Example:
4*5\ 4*5\
Typ4*5
]
Specify input 4 video type as YUVi.
N
To set input 6 to SDI video on a scaler equipped with an optional SDI/HD-SDI input board, enter the command 6*8\, to which the switcher responds Typ8
]
.
To set input 6 to HD-SDI video on a scaler equipped with an optional SDI/HD-SDI input board, enter the command 6*9\, to which the switcher responds Typ9
]
.
View input video type
X!
\
X!
\
X1)]
Input
X!
video type is
X1)
.
Output video settings
Set resolution and refresh rate
X1!
*
X1@
=
X1!
*
X1@
= Rte
X1!
*
X1@]
Command character is “equals”.
Example:
4*4= 4*4=
Rte04*4
]
Set output to 1024x768 at 96 Hz.
View resolution and refresh rate = =
X1!
*
X1@]
Set output sync format
6*
X1#
# 6*
X1#
# Syn
X1#]
Example:
6*0# 6*0#
Syn0
]
Set output sync format to RGBHV.
View output sync format 6# 6#
X1#]
Set output sync polarity
7*
X1$
# 7*
X1$
# Pol
X1$]
Example:
7*0# 7*0#
Pol0
]
Set output sync polarity to H-/V-.
View output sync polarity 7# 7#
X1$]
N
X!
= Input number 1 – 6
X@
= Output number 1 = Program 2 = Preview 3 = PIP window 4 = PIP image
X1)
= Video type 1 = RGB 4 = RGBcvS 7 = Composite 10 = Auto SDI (input 6 only)
2 = YUV-HD 5 = YUVi 8 = SDI (input 6 only) 11 = Auto YUV
3 = YUVp 6 = S-video 9 = HD-SDI (input 6 only)
X1!
= Switcher resolution 01 = 640x480 06 = 1024x1024 11 = 1366x768 16 = 576p 21 = 1280x800
02 = 800x600 07 = 1280x768 12 = 1365x1024 17 = 720p 22 = 1440x900
03 = 852x480 08 = 1280x1024 13 = 1400x1050 18 = 1080i 23 = 1680x1050
04 = 1024x768 09 = 1360x765 14 = 1600x1200 19 = 1080p 24 = 1080p Sharp
05 = 1024x852 10 = 1365x768 15 = 480p 20 = 1864x1050 5 = 1920x1200.
X1@
= Video refresh rate 1 = 50 Hz 3 = 72 Hz 5 = 100 Hz 7 = 24 Hz 9 = 30 Hz
2 = 60 Hz 4 = 96 Hz 6 = 120 Hz 8 = 25 Hz 10 = 59.94 Hz
X1#
= Output video type 0 = RGBHV 1 = RGsB 2 = YUV bi-level 3 = YUV tri-level
X1$
= Output sync polarity 0 = H-/V- 1 = H-/V+ 2 = H+/V- 3 = H+/V+
