ISS 506 Integration Seamless Switcher • Operation
Capturing a logo
The ISS can capture an on-screen image to use as a logo.
N
A logo is a bitmap image that can be superimposed on top of the preview and/or
program output.
Capture a displayed image as a logo as follows:
1
. Press the Menu button until the LCD window displays the Logo Capture
Menu (figure 3-24).
30 sec.
Press
5 times
To
Figure 3-25
Press
X-Axis
Y-Axis
30 sec. 30 sec.
0000
through
upper H size
0000
through
upper V size
Default
Cycle
Logo
Capture
Capture Start
X=0001 Y=0001
Image Source
<
Prog
>
Prev
MENU
NEXT
Press
NEXT
Step
1
Step
2
Step
4
Press
NEXT
Step
6
Rotate the knobs to
select the source of
the image to capture.
Rotate the knobs to
move the upper-left
corner of the image
area to be captured.
Step
3
Step
5
Figure 3-24 — Capturing a logo
2. Press the Next button. The Image Source submenu appears.
3. Rotate the Adjust
{
knob to select (< >) the output with the image that you
want to capture.
4
. Press the Next button. The Capture Start submenu appears on the LCD
window. Yellow crop marks appear on the selected output video display.
5
. Use the Adjust knobs to shift the starting point (upper-left corner) of the
capture area.
N
Rotate the Adjust
[
knob to shift the starting point on the X axis (horizontally).
Rotate the Adjust
{
knob to shift the starting point on the Y axis (vertically).
