ISS 506 Integration Seamless Switcher • SIS
Programming and Control
Picture adjustments
X@
Col
X2&
]
A front panel color adjustment has occurred.
X@
is the output (program or preview)
switched to the adjusted input and
X2&
is the color variable.
X@
Tin
X2&
]
A front panel tint adjustment has occurred.
X@
is the output (program or preview)
switched to the adjusted input and
X2&
is the tint variable.
X@
Brt
X2&
]
A front panel color brightness adjustment has occurred.
X@
is the output (program
or preview) switched to the adjusted input and
X2&
is the brightness variable.
X@
Con
X2&
]
A front panel contrast adjustment has occurred.
X@
is the output (program or
preview) switched to the adjusted input and
X2&
is the contrast variable.
X@
Hsz
X1^
]
A front panel horizontal size adjustment has occurred.
X@
is the output (program
or preview) and
X1^
is the size variable.
X@
Vsz
X1^
]
A front panel vertical size adjustment has occurred.
X@
is the output (program or
preview) and
X1^
is the size variable.
X@
Hph
X1&
]
A front panel horizontal centering adjustment has occurred.
X@
is the output
(program or preview) and
X1&
is the centering variable.
X@
Vph
X1&
]
A front panel vertical centering adjustment has occurred.
X@
is the output
(program or preview) and
X1&
is the centering variable.
X@
Phs
X!*X2)
]
A front panel pixel phase adjustment has occurred.
X@
is the output (program or
preview).
X!
is the input.
X2)
is the pixel phase variable.
X@
Det
X2&
]
A front panel horizontal detail filter adjustment has occurred on the input switched
to output
X@
.
X2&
is the filter variable.
7Dvz
X4!
]
A front panel flicker (vertical) filter adjustment has occurred for the optional scan
converter output board.
X4!
is the filter variable.
7Dhz
X4!
]
A front panel horizontal filter adjustment has occurred for the optional scan
converter output board.
X4!
is the filter variable.
7Enc
X4@
]
A front panel encoder filter adjustment has occurred for the optional scan converter
output board.
X4@
is the filter variable.
Blu
X1%
]
The blue-only mode has been turned on or off from the front panel for one or both
outputs.
X1%
is the on/off status for the two outputs.
