ISS 506 Integration Seamless Switcher • SIS
Programming and Control
4-22
Command/response table for SIS commands (continued)
Command ASCII (Telnet)
(host to switcher)
URL Encoded (Web)
(host to switcher)
Response
(switcher to host)
Additional description
Contrast
Set a specific contrast value
X@
*
X2&
^
X@
*
X2&
^
X@
Con
X2&]
Set the
X@
output contrast value to
X2&
.
Increment contrast value
X@
+^
X@
+^
X@
Con
X2&]
Increase the
X@
output contrast setting by one.
Decrement contrast value
X@
-^
X@
-^
X@
Con
X2&]
Decrease the
X@
output contrast setting by one.
View the contrast value
X@
^
X@
^
X2&]
Show the contrast setting.
Brightness
Set a specific brightness value
X@
*
X2&
Y
X@
*
X2&
Y
X@
Brt
X2&]
Set the
X@
output brightness value to
X2&
.
Increment brightness value
X@
+Y
X@
+Y
X@
Brt
X2&]
Increase the
X@
output brighness setting by one.
Decrement brightness value
X@
-Y
X@
-Y
X@
Brt
X2&]
Decrease the
X@
output brightness setting by
one.
View the brightness value
X@
Y
X@
Y
X2&]
Show the brightness setting.
Detail filter
N
The command (D or d) is not case sensitive except when used in conjunction with the optional scan converter output board. See the Optional Scan converter board commands,
on page 4-30.
Set detail level
X@
*
X2&
D
X@
*
X2&
D
X@
Det
X2&]
Specify the
X@
output detail level.
Increment detail level
X@
+D
X@
+D
X@
Det
X2&]
Increase the detail level by one step.
Decrement detail level
X@
-D
X@
-D
X@
Det
X2&]
Decrease the detail level by one step.
View detail level
X@
D
X@
D
X2&]
Show the detail level.
Display Setup Tools
Test pattern
Turn on test pattern
X2*
*
X2(
J
X2*
*
X2(\
J Tst
X2*
*
X2(]
Select test pattern
X2(
for the preview and/or
program output.
Example:
1*0J 1*0J
Tst01*00
]
Select the Color Bars test pattern for the
program output only.
Turn off test pattern
0*
X2(
J 0*
X2(
J Tst0*
X2(]
Turn off test pattern for both outputs.
View test pattern on/off status J J
X2*
*
X2(]
N
X@
= Output number 1 = Program 2 = Preview 3 = PIP window 4 = PIP image
X2&
= Picture adjustments 000 – 127
(color, tint, brightness, detail)
X2*
= Prog/prev output selection 0 = prog off / prev off 1 = prog on / prev off 2 = prog off / prev on 3 = prog on / prev on
X2(
= Test pattern type 00 = Color Bars 01 = crosshatch 4:3 02 = 4x4 crosshatch 03 = Split grayscale
04 = Ramp 05 = Alternating pixels 06 = Crop 07 = Aspect ratio 1.33
08 = Aspect ratio 1.7 09 = Aspect ratio 1.85 10 = Aspect ratio 2.35
